9001914996 (040104) SMH4HTX02G

*9001914996* Quick reference guide Dishwasher

en Before using for the first time, read the instruction manual and the safety information it contains.

Setting up Home Connect

Tip:Connect your appliance to a mobile device. You can con-

veniently change all settings using the HomeConnect app.

1. Install the HomeConnect app on your mobile device and fol-

low the instructions.

2. Scan the QR code with the HomeConnect

app.

Overview of water hardness settings

You can find an overview of the

water hardness values that can

be selected here.

A table of country-specific units

can be found in the instruction

manual.

Hardness

range

mmol/l Setting

value

Soft 0 - 1.1 H00

Soft 1.2 - 1.4 H01

Medium 1.5 - 1.8 H02

Medium 1.9 - 2.1 H03

Medium 2.2 - 2.9 H04

Hard 3.0 - 3.7 H05

Hard 3.8 - 5.4 H06

Hard 5.5 - 8.9 H07

Setting the water softening sys-

tem

1. Press .

2. To open the basic settings, press

for 3 seconds.

aThe display shows Hxx.

aThe display shows .

3. Press repeatedly until the right

water hardness has been set.

4. To save the settings, press

for 3 seconds.

Adding special salt

To avoid damage to the appliance, only add special

salt to the dispenser for special salt just before the

programme starts.

1. Unscrew the lid of the dispenser for special salt

and remove.

2. On initial start-up: Fill the dispenser right up with

water.

3. Add the special salt to the

dispenser. The water in the

dispenser is displaced and

forced out. Never add de-

tergent.

4. Place the lid back on the dispenser and turn to

close.

Adding rinse aid

1. Press the catch on the lid

of the dispenser for rinse

aid and lift .

2. Add rinse aid up to the

max mark.

max

3. Close the lid of the dispenser for rinse aid.

aThe lid clicks into position.

How to use your appliance

1. Load the tableware.

Only clean tableware that is suitable for dish-

washers. Remove large remnants of food from

the tableware. Check that the spray arms can ro-

tate freely.

2. Add detergent.

3. Switch on the appliance .

4. Select the programme.

5. Start the programme .

6. Remove the tableware at the end of the pro-

gramme.

7. To cancel the programme, press for

approx. 4seconds.

The programme is cancelled and ends after ap-

prox. 1minute.

Programmes

The programme data has been meas-

ured in the laboratory according to

European standard EN60436.

The consumption figures depend on

the programme and additional func-

tion selected.

The running time will change if the

rinse aid system is switched off or

rinse aid needs to be added.

Programme 1) Duration [h:min]

2) Energy consump-

tion [kWh]

3) Water [l]

Intensive 70°

1) 2:05 -2:15

2) 1.350 -1.400

3) 10.5 -13.5

Auto 45-65°

1) 1:40-2:45

2) 0.850-1.450

3) 7.0-15.5

Eco 50°

1) 4:30

2) 0.836

3) 9.0

Glass 40°

1) 1:40-1:45

2) 0.750-0.800

3) 11.5-14.0

Express 65° - 1h

1) 1:00

2) 1.200

3) 10.0

Machine Care

1) 2:10

2) 1.350

3) 15.1

Favourite

1) 0:15-0:15

2) 0.050-0.050

3) 4.0-4.0

Adding detergent

1. Add the detergent to the

dry detergent dispenser.

15 ml

25 ml

50 ml

2. Close the lid of the deter-

gent dispenser.

aThe lid clicks into position.

Cleaning filters

1. After each wash check the filters for

residue.

2. Turn the coarse

filter anticlock-

wise and re-

move the filter

system .

3. Pull down the mi-

cro filter to re-

move.

4. Press the locking

catches to-

gether and lift

the coarse filter

out .

5. Clean the filter elements under running

water.

6. Re-assemble the filter system.

7. Insert the filter system into the appliance

and turn the coarse filter clockwise.

Make sure that the arrow markings

match up.

Cleaning spray arms

1. Unscrew the upper spray arm and

pull down to remove .

2. Pull up the lower spray arm to remove.

3. Check the outlet nozzles on the spray arms for blockages un-

der running water and remove any foreign bodies.

4. Insert the lower spray arm.

aThe spray arm clicks into position.

5. Insert the upper spray arm and screw it firmly in place.

Clean wastewater pump

1. Disconnect the appliance from the power supply.

2. Remove the filter system.

3. Scoop out any water.

4. Prise off the pump cover using a

spoon and grip it by the crosspiece.

5. Lift the pump cover inwards at an angle and remove.

6. Remove any remnants of food and foreign bodies in the area

of the impeller.

7. Insert the pump cover and press

down .

aThe pump cover clicks into position.

8. Install the filter system.

Troubleshooting

Fault Cause and troubleshooting

E:32-00 will light up al-

ternately or indicator for

water supply lights up.

Supply hose is kinked.

▶Install the supply hose without kinks.

Water tap is turned off.

▶Turn on the water tap.

Water tap is jammed or furred up.

▶Turn on the water tap.

The flow rate must be at least 10 l/min when the water sup-

ply is open.

The filters in the water connection of the supply or AquaStop

hose are blocked.

1. Switch off the appliance.

2. Pull out the mains plug.

3. Turn off the water tap.

4. Unscrew the water connection.

5. Remove the filter from the sup-

ply hose

6. Clean the filter.

7. Re-insert the filter in the supply hose.

8. Screw the water connection back on.

9. Check the water connection for leaks.

10. Restore the power supply.

11. Switch the appliance on.

Fault Cause and troubleshooting

E:61-02 will light up al-

ternately.

Wastewater pump is blocked.

▶Clean the wastewater pump.

Cover of the wastewater pump is loose

▶Secure the cover of the Wastewater pump so it clicks into

position.

E:92-40 will light up al-

ternately.

Filters are soiled or blocked.

▶Clean the filters.

Remnants of food on

tableware.

Tableware is placed too close together or basket is overfilled.

1. Arrange tableware with sufficient space in between.

The spray jets must reach the surfaces of the tableware.

2. Avoid points of contact.

Spray arm rotation is blocked.

▶Arrange tableware so that it does not obstruct spray arm ro-

tation.

Spray arm nozzles are blocked.

▶Clean the Spray arms.

Filters are soiled.

▶Clean the filters.

Filters are inserted incorrectly and/or not engaged.

1. Insert the filters properly.

2. Engage the filters.

Washing programme selected too weak.

▶Select a more intensive washing programme.

Fault Cause and troubleshooting

Removable streaks are

present on glasses, glass-

ware with a metallic ap-

pearance and cutlery.

Amount of rinse aid to be dispensed is set too high.

▶Set the rinse aid system to a lower setting.

No rinse aid has been added.

▶Add rinse aid.

Rust spots on cutlery. Cutlery is not sufficiently rust-resistant. Knife blades are often

more severely affected.

▶Use rust-resistant tableware.

Cutlery may also rust if washed together with rusting items.

▶Do not wash rusting items.

Detergent residue is

present in the detergent

dispenser or the tablet

collecting tray.

Spray arms were blocked by tableware so detergent was not

rinsed out.

▶Check that the spray arms are not blocked and can rotate

freely.

All LEDs light up or flash

or the rinse programme

does not continue run-

ning.

Electronics have detected a fault.

▶Press the main switch button for approx. 4seconds.

The appliance is reset and restarted.
