Manufactured in China for:
Blue Rhino Global Sourcing, LLC
Winston-Salem, NC USA
1.800.762.1142, www.bluerhino.com
© 2006 Blue Rhino Global Sourcing, LLC. All Rights Reserved
UniFlame® is a Registered Trademark of Blue Rhino Global Sourcing, LLC. All Rights Reserved
WAD506B_506AS_6180AP-OM-100 E
WARNING
FOR YOUR SAFETY:
1. Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage.
2. Read the installation, operation, and
maintenance instructions thoroughly before
installing or servicing this equipment.
3. Failure to follow these instructions could
result in fire or explosion, which could
cause property damage, personal injury, or
death.
Save these instructions for future reference.
If you are assembling this unit for someone else,
give this manual to him or her to read and save
for future reference.
WARNING
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
Outdoor Fireplace
Model No. WAD506AS, WAD506B & WAD6180AP
OWNER’S MANUAL
Table of Contents
Important Safeguards Page 2...........................................
Exploded View & Hardware 3...........................................
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Operating Instructions 6...............................................
Lighting 6........................................................
Tending the Fire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Extinguishing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Inspecting 6......................................................
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Storing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Product Registration 6................................................
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Outdoor Fireplace Model No. WAD506AS, WAD506B, WAD6180AP
Contact 1.800.762.1142 for assistan
WARNING
FOR YOUR SAFETY
1. This appliance is for outdoor use only, and shall NOT be used in a
building, garage, or any other enclosed area.
2. Do NOT use this outdoor fireplace for indoor heating. TOXIC carbon
monoxide fumes can accumulate and cause asphyxiation.
3. This outdoor fireplace is NOT for commercial use.
4. This outdoor fireplace is NOT to be operated by children.
5. This outdoor fireplace is NOT to be used in or on boats or recreational
vehicles.
6. Always use in accordance with all applicable local, state and national
codes. Contact your local fire department for details on outdoor
burning.
7. When using this outdoor fireplace, exercise the same precautions you
would with any open fire.
8. The use of alcohol, prescription or non-prescription drugs may impair
the consumer’s ability to properly assemble or safely operate this
outdoor fireplace.
9. Do NOT use this outdoor fireplace without reading the entire “Owner’s
Manual”.
10. This outdoor fireplace is for use with dry, seasoned hardwood. It will
burn hotter, more completely and create less smoke.
11. Do NOT burn charcoal briquets, lump charcoal, manufactured logs,
driftwood, trash, leaves, paper, cardboard, plywood, painted or stained
or pressure treated wood. Avoid using softwoods such as pine or
cedar that can throw sparks.
12. Do NOT alter this outdoor fireplace in any manner.
13. Do NOT use this outdoor fireplace until it is COMPLETELY assembled
and all parts are securely fastened and tightened.
14. Do NOT store or use gasoline or other flammable vapors or liquids in
the vicinity of this or any other appliance.
15. Do NOT store or use an LP gas cylinder within 10 feet (3.05 m) of this
outdoor fireplace while it is in operation.
16. Do NOT use this outdoor fireplace near automobiles, trucks, vans or
recreational vehicles.
17. Do NOT use in an explosive atmosphere. Keep outdoor fireplace
area clear and free from combustible materials, gasoline and other
flammable liquids.
18. Do NOT use this outdoor fireplace under any overhead or near any
unprotected combustible constructions. Avoid using near or under
overhanging trees and shrubs.
19. Always use this outdoor fireplace on a hard, level non-combustible
surface such a concrete, rock or stone. An asphalt or blacktop surface
may not be acceptable for this purpose. Do NOT use on wooden decks.
20. Always empty this outdoor fireplace before each use.
21. Do NOT wear flammable or loose clothing when operating this outdoor
fireplace.
22. Do NOT use in windy conditions.
23. Do NOT use this outdoor fireplace unless spark guards are securely
in place.
24. Do NOT use gasoline, kerosene, diesel fuel, lighter fluid or alcohol to
light or relight fires.
25. Keep all electrical cords away from a hot fireplace.
26. All surfaces of this outdoor fireplace are hot when in operation. To
avoid burns, do NOT touch fireplace until it has completely cooled
unless you are wearing protective gear (Potholders, gloves, BBQ
mittens, hot pads & etc.). Never touch ashes or coals to see if they
are hot.
27. Do NOT leave a lit outdoor fireplace unattended, especially around
children and pets.
28. Do NOT attempt to move or store this outdoor fireplace until all ashes
and coals are completely extinguished.
29. Do NOT remove ashes or coals until they are completely and fully
extinguished.
30. Use heat-resistant gloves or hot pads when contacting handles.
31. Use long, sturdy fireplace tools when adding or moving logs.
32. Do NOT place wood directly into bottom of the outdoor fireplace. Place
wood only on the wood grid.
33. Do NOT overload the fireplace. Do not add additional firewood until
the fire burns down. NOTICE: If any portion of the bowl, lid or spark
guards of this outdoor fireplace are glowing red it is overloaded.
34. Do NOT lean over this outdoor fireplace when lighting or when in use.
35. Do NOT place a hot spark guard or hot fireplace tools onto
combustible surfaces such as grass, wooden deck or furniture.
36. Avoid breathing smoke from the fire and avoid getting it into
your eyes.
37. This outdoor fireplace should be thoroughly inspected and cleaned on
a regular basis.
38. After a period of storage and/or non-use, check for signs of damage
and creosote build-up. Do NOT operate until necessary repairs and/or
cleanup are executed.
39. Use only Blue Rhino Global Sourcing, LLC factory authorized parts. The
use of any part that is NOT factory authorized can be dangerous and
will void your warranty.
40. Please use protective gloves when assembling this product.
41. Do not force parts together as this can result in personal injury or
damage to the product.
42. Deaths, serious injury or damage to property may occur if the above
is not followed exactly.
Contact 1.800.762.1142 for assistance. Do not return to place of purchase.
page no.
3
1
2
3
4
5
Parts List
1Handle
2Spark Guard
3Wood Grid
4Bowl
5Base Ring
6Hearth (4)
7Ash Receiver
8Leg (4)
9Leg Ring
Hardware
AScrew M5x10 Black Nickel Plated Plate Head 6 pcs
BCap Nut M8 Black Nickel Plated 20 pcs
CLock Washer ø5 Black Nickel Plated 2 pcs
DLock Washer ø8 Black Nickel Plated 20 pcs
Tools Required for Assembly (Included)
M8 Wrench
Tools Required for Assembly (Not Included)
#2 Phillips Head Screwdriver
Exploded View
6
6
6
6
7
9
88
