Manufactured in China for: Blue Rhino Global Sourcing, Inc.
Winston-Salem, NC 27105 USA • 1.800.762.1142 • BlueRhino.com
© Blue Rhino Global Sourcing, Inc.
Endless Summer® is a Registered Trademark of Blue Rhino Global Sourcing, Inc. GAD15021M-OM-101 EF
LP Gas Outdoor Fireplace
Model No. GAD15021M
®OWNER’S MANUAL
Table of Contents
Important Safeguards Page 2...........................................
Expanded View and Hardware 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Assembly Instructions 5...............................................
Installing LP Gas Tank 7...............................................
Operating Instructions 7...............................................
Cleaning and Care 8 .................................................
Product Registration 8................................................
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Limited Warranty .................................................. 8
Troubleshooting 9 ...................................................
The use and installation of this product must conform to local codes. In absence of local codes,
use the latest edition of the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or International
Fuel Gas Code. This appliance, when installed, must be electrically grounded in accordance
with local codes, or in the absence of local codes with the National Electrical Code, ANSI/NFPA
70, if applicable.
For installation in Canada - these instructions, while generally acceptable, do not necessarily
comply with the Canadian installation codes, particularly with piping above and below ground.
In Canada the installation of this appliance must comply with local codes and/or standard CAN/
CGA B149.1 (installation code for propane burning appliances and equipment).
California Proposition 65: Combustion by-products produced when using this product
contain chemicals known to the State of California to cause cancer, birth defects, and other
reproductive harm.
California Proposition 65: Wash your hands after handling this product.
DANGER CARBON MONOXIDE HAZARD
• This appliance can produce carbon
monoxide which has no odor.
• Using it in an enclosed space can kill you.
• Never use this appliance in an enclosed
space such as a camper, tent, car or home.
WARNING
FOR YOUR SAFETY:
For Outdoor Use Only (outside any enclosure)
Do Not Use For Cooking.
WARNING
FOR YOUR SAFETY:
WIf the information in this manual is not
followed exactly, a fire or explosion may
result causing property damage, personal
injury or loss of life.
WWHAT TO DO IF YOU SMELL GAS:
• Do try lighting any appliance.NOT
• Do NOT touch any electrical switch; do
NOT use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone.
• Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call
the fire department.
WInstallation and service must be performed
by a qualified installer, service agency or
gas supplier.
WSave these instructions for future
reference.
WIf you are assembling this unit for someone
else, give this manual to him or her to read
and save for future reference.
Made from 75% Bagasse
(environmentally friendly sugar
cane pulp by-product)
WARNING
FOR YOUR SAFETY:
Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage.
Read the installation, operation and
maintenance instructions thoroughly before
installing or servicing this equipment.
DANGER
If you smell gas:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
WARNING
FOR YOUR SAFETY:
1. Do NOT store or use gasoline or other
flammable vapors or liquids in the vicinity of
this or any other appliance.
2. An LP-cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
DANGER
Do leave this appliance unattended while NOT
it is in operation.
®
LP Gas Outdoor Fireplace
Model No. GAD15021M Series
2
WThis appliance is for outdoor use only, and should NOT be used in a
building, garage or any other enclosed area.
WDo NOT operate, light or use this appliance within ten feet (3.05 m) of
walls, structures or buildings.
WFor residential use only. This outdoor fireplace is NOT for commercial
use.
WDo NOT use this outdoor fireplace for indoor heating. TOXIC carbon
monoxide fumes can accumulate and cause asphyxiation.
WThis outdoor fireplace is safety certified for use in the United States
and/or Canada only. Do modify for use in any other location. NOT
Modification will result in a safety hazard and will void your warranty.
WApartment dwellers: Check with management to learn the requirements
and fire codes for using a liquid propane (LP) gas outdoor fireplace in
your apartment complex. If allowed, use outside on the ground floor
with a ten foot (3.05 m) clearance from any structure. Do NOT use on or
under balconies.
WThis outdoor fireplace, from the factory, is for use with LP gas only. The
conversion to or attempted use of natural gas in this outdoor fireplace is
dangerous, may cause bodily harm and will void your warranty.
WLP gas characteristics:
a. LP gas is flammable and hazardous if handled improperly. Become
aware of the characteristics before using any LP gas product.
b. LP gas is explosive under pressure, heavier than air, and settles/
pools in low areas.
c. LP gas in its natural state has no odor. For your safety, an odorant is
added that smells like rotten cabbage.
d. Contact with LP gas can cause freeze burns to skin.
WLP gas tank needed to operate. Only tanks marked “propane” may be
used.
a. The LP gas cylinder must be constructed and marked in accordance
with the U.S. Department of Transportation (D.O.T.) Specifications for
LP-Gas Cylinders, Standard for Cylinders, Spheres and Tubes or the
for the Transportation of Dangerous Goods and Commission CAN/,
CSA-B339 as applicable.
b. LP gas tank must be arranged for vapor withdrawal.
c. The LP gas tank must have a listed overfilling prevention device
(OPD) and a QCCI or Type I (CGA810) LP gas tank connection.
d. The LP gas tank must have a tank collar to protect the tank valve.
e. Never use an LP gas tank with a damaged body, valve, collar or
footing.
f. Dented or rusted LP gas tanks may be hazardous and should be
checked by your LP gas supplier prior to use.
g. The LP gas tank should not be dropped or handled roughly.
h. Tanks must be stored outdoors, out of the reach of children and
must not be stored in a building, garage or any other enclosed area.
Your LP gas tank must never be stored where temperatures can
reach over 125°F.
i. Do NOT insert any tool or foreign object into the valve outlet or
safety relief valve. You may damage the valve and cause a leak.
Leaking propane may result in explosion, fire, severe personal injury
or death.
j. Never keep an LP gas tank in a hot car or trunk. Heat will cause the
gas pressure to increase, which may open the relief valve and allow
gas to escape.
k. Place dust cap on cylinder valve outlet whenever the cylinder is not
in use. Only install the type of dust cap on the cylinder valve outlet
that is provided with the cylinder valve. Other types of caps or plugs
may result in leakage of propane.
l. Do NOT store a spare LP gas tank under or near this appliance.
m. Never fill the cylinder beyond 80 percent full.
n. A fire causing serious injury or damage to property may occur if the
above is not followed exactly.
WYour outdoor fireplace has been checked at all factory connections
for leaks. Recheck all connections as described in the “Operating
Instructions” section, as shipping can loosen connections.
WCheck for leaks even if your unit was assembled for you by someone
else.
WDo operate if a gas leak is present. Gas leaks may cause a fire or NOT
explosion.
WYou must follow all instructions in the “Checking for Leaks” section
before operating. To prevent a fire or explosion when testing for a leak:
a. Always perform a leak test before lighting this outdoor fireplace and
each time the tank is connected for use.
b. No smoking. Do use or permit sources of ignition in the area NOT
while conducting a leak test.
c. Conduct the leak test outdoors in a well-ventilated area.
d. Do use matches, lighters or a flame to check for leaks. NOT
e. The use of alcohol, prescription or non-prescription drugs may
impair the consumer’s ability to properly assemble or safely operate
the appliance.
f. Strong odors, colds, sinus congestion, etc. may prevent the
detection of propane. Use caution and common sense when testing
for leaks.
g. Do use this outdoor fireplace until any and all leaks are NOT
corrected.
If you are unable to stop a leak, disconnect the LP gas supply. Call a
gas appliance serviceman or your local LP gas supplier.
WDo store or use gasoline or other flammable liquids or vapors NOT
within 25 feet (7.62 m) of this appliance.
WDo NOT use in an explosive atmosphere. Keep outdoor fireplace
area clear and free from combustible materials, gasoline and other
flammable vapors and liquids.
WThis outdoor fireplace is NOT to be operated by children.
WThis outdoor fireplace is NOT to be used in or on boats or recreational
vehicles.
WDo NOT connect to a remote gas supply.
WNever attempt to attach this outdoor fireplace to the self-contained LP
gas system of a camper trailer, motor home or house.
WAlways use in accordance with all applicable local, state and national
codes. Contact your local fire department for details on outdoor burning.
WWhen using this outdoor fireplace, exercise the same precautions you
would with any open fire.
WDo NOT use this outdoor fireplace without reading the entire Owner’s
Manual.
WDo NOT burn solid fuels such as: wood, charcoal briquettes, lump
charcoal, manufactured logs, driftwood, trash, leaves, paper, cardboard,
plywood, painted/stained/pressure treated wood in this outdoor
fireplace.
WIt is essential to keep the outdoor fireplace’s valve compartment,
burners, and circulating air passages clean. Inspect outdoor fireplace
before each use.
WDo NOT use this outdoor fireplace until it is COMPLETELY assembled and
all parts are securely fastened and tightened.
WDo NOT use this outdoor fireplace near automobiles, trucks, vans or
recreational vehicles.
WDo NOT use this outdoor fireplace under any overhang or near any
unprotected combustible constructions. Avoid using near or under
overhanging trees and shrubs.
WAlways use this outdoor fireplace on a hard, level, non-combustible
surface such as concrete, rock or stone. An asphalt or blacktop surface
may not be acceptable for this purpose.
WDo NOT use this outdoor fireplace for cooking.
WDANGER: Failure to follow the dangers, warnings and cautions in this manual may result in serious bodily injury or death, or in a fire or an explosion
causing damage to property.
WWARNINGS:
DANGERS and WARNINGS: FOR YOUR SAFETY
Need help? 1.800.762.1142
Do not return to place of purchase.
Replacement Parts
parts.BlueRhino.com
1.800.762.1142
3
WDo NOT use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the appliance
and to replace any part or control system and any gas control which
has been under water.
WDo NOT wear flammable or loose clothing when operating this outdoor
fireplace.
WDo NOT use in windy conditions.
WNever lean over this outdoor fireplace when lighting or when in use.
WDo NOT use this outdoor fireplace unless burner is securely in place.
WKeep all electrical cords away from this outdoor fireplace during use.
WCertain areas of this outdoor fireplace when in use will become too
hot to touch. To avoid burns, do touch hot surfaces until the unit NOT
has completely cooled (about 45 minutes), unless you are wearing
protective gear (such as insulated pot holders or heat-resistant gloves/
mittens).
WDo NOT leave a lit outdoor fireplace unattended, especially around
children and pets.
WChildren and adults should be alerted to the hazards of high surface
temperatures and should stay away to avoid burns or clothing ignition.
WYoung children should be carefully supervised when they are in the area
of the appliance.
WDo NOT hang or place clothing or other flammable material on or near
this appliance.
WAny guard or other protective device removed for servicing the
appliance must be replaced prior to operating the appliance.
WIf applicable, protective cover must be removed when burner is in
operation.
WDo NOT attempt to move outdoor fireplace when in use. Allow the
outdoor fireplace to cool before moving or storing.
WThis outdoor fireplace should be thoroughly cleaned and inspected
on a regular basis. Clean and inspect the hose before each use of the
appliance. If there is evidence of abrasion, wear, cuts, or leaks, the hose
must be replaced prior to the appliance being operated.
WThis outdoor fireplace should be inspected at least annually by a
qualified service person. Depending on amount of use, more frequent
cleaning may be required. Do NOT operate until all parts have been
repaired or replaced.
WUse only the regulator and hose assembly provided. Use only the
replacement regulator and hose assembly specified by Blue Rhino
Global Sourcing, Inc.
WUse only Blue Rhino Global Sourcing, Inc. factory-authorized parts. The
use of any part that is not factory-authorized can be dangerous and will
void your warranty.
WDo NOT operate this appliance without reading “Operating Instructions”
in this manual.
WStorage of this outdoor fireplace indoors is permissible only if the tank
is disconnected, removed from the outdoor fireplace and properly stored
outdoors.
WDo NOT attempt to disconnect the gas regulator from the tank or any
gas fitting while the outdoor fireplace is in use.
WIf the outdoor fireplace is not in use, the gas must be turned off at the
supply tank.
WThe pressure regulator is set for 11 inches of water column.
WThe maximum inlet gas pressure for this outdoor fireplace is 11 inches
of water column.
WBefore pressure testing, close LP gas tank valve and disconnect gas
regulator. The gas supply piping system must test at pressures equal to
or less than ½ psi (3.5 kPa).
WDo NOT sit or stand on the mantle or any part of this appliance.
WDo NOT throw anything onto the fire when the unit is in operation.
WFire logs, glass and lava rock are very hot. Keep children or pets at a
safe distance from this appliance.
WThe opening of the tank collar should face toward the door side for easy
access.
WDo NOT store any combustible materials in the base enclosure.
WUse protective gloves when assembling this product.
WDo NOT force parts together as this can result in personal injury or
damage to the product.
WDeath, serious injury or damage to property may occur if the above is
not followed exactly.
Produktspezifikationen
| Marke: | Blue Rhino |
| Kategorie: | Offener Herd |
| Modell: | GAD15021M |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Blue Rhino GAD15021M benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Offener Herd Blue Rhino
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
Bedienungsanleitung Offener Herd
- Offener Herd Tristar
- Offener Herd SilverCrest
- Offener Herd Cotech
- Offener Herd Ambiano
- Offener Herd Ardes
- Offener Herd Klarstein
- Offener Herd Bomann
- Offener Herd Taurus
- Offener Herd Smeg
- Offener Herd Einhell
- Offener Herd Eurom
- Offener Herd Bimar
- Offener Herd Fieldmann
- Offener Herd Qlima
- Offener Herd Dimplex
- Offener Herd Faber
- Offener Herd Manor House
- Offener Herd EWT
- Offener Herd Sylvania
- Offener Herd Invicta
- Offener Herd La Nordica
- Offener Herd Blumfeldt
- Offener Herd Hwam
- Offener Herd Orbegozo
- Offener Herd Napoleon
- Offener Herd Furrion
- Offener Herd Jøtul
- Offener Herd Haas+Sohn
- Offener Herd Edilkamin
- Offener Herd Element4
- Offener Herd Firefriend
- Offener Herd Norsk Kleber
- Offener Herd Spartherm
- Offener Herd Well Straler
- Offener Herd Lasko
- Offener Herd Amantii
- Offener Herd Brixton
- Offener Herd Euromac
- Offener Herd Deville
- Offener Herd Uniflame
Neueste Bedienungsanleitung für -Kategorien-
7 Oktober 2024
5 Oktober 2024
5 Oktober 2024
5 Oktober 2024
3 Oktober 2024
3 Oktober 2024
1 Oktober 2024
1 Oktober 2024
1 Oktober 2024
1 Oktober 2024
