A57A Setup Manual
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee
that interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the
contents here and specially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make changes to the contents here without obligation to
notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor’s approval in writing.
The content of this user’s manual is subject to be changed without notice and
we will not be responsible for any mistakes found in this user’s manual. All the
brand and product names are trademarks of their respective companies.
Dichiarazione di conformitĂ
sintetica
Ai sensi dell’art. 2 comma 3 del D.M.
275 del 30/10/2002
Si dichiara che questo prodotto è
conform e alle normative vigenti e
s oddisfa i requisiti essenziali richies ti
dalle direttive
2004/108/CE, 2006/95/CE e
1999/05/CE
quando ad esso applicabili
Short Declaration of conformity
We declare this product is complying
with the laws in force and meeting all
the essential requirem ents as s pecified
by the directives
2004/108/CE, 2006/95/CE and
1999/05/CE
whenever thes e laws may be applied
Table of Contents
Chapter 1: Introduction ................................................................ 1
1.1 Before You Start ....................................................................................1
1.2 Package Checklist .................................................................................1
1.3 Motherboard Features...........................................................................2
1.4 Rear Panel Connectors ..........................................................................3
1.5 Motherboard Layout .............................................................................4
Chapter 2: Hardware Installation .................................................. 5
2.1 Installing Central Processing Unit (CPU)...............................................5
2.2 FAN Headers .........................................................................................7
2.3 Installing System Memory......................................................................8
2.4 Connectors and Slots............................................................................10
Chapter 3: Headers & Jumpers Setup........................................... 13
3.1 How to Setup Jumpers ......................................................................... 13
3.2 Detail Settings...................................................................................... 13
Chapter 4: RAID Functions.......................................................... 17
4.1 Operating System................................................................................17
4.2 Raid Arrays.......................................................................................... 17
4.3 How RAID Works.................................................................................17
Chapter 5: Useful Help................................................................ 20
5.1 Driver Installation Note.......................................................................20
5.2 Software............................................................................................... 21
5.3 Extra Information................................................................................23
5.4 AMI BIOS Beep Code............................................................................24
5.5 Troubleshooting...................................................................................25
Chapter 6: bios update ............................................................... 26
6.1 BIOS Update Utility.............................................................................26
6.2 Online Update Utility ..........................................................................28
6.3 BIOSTAR BIOS Flasher .........................................................................30
Appendix: SPEC In Other Languages............................................ 32
German ....................................................................................................................32
French....................................................................................................................... 34
Italian.......................................................................................................................36
Spanish ..................................................................................................................... 38
Portuguese ............................................................................................................... 40
Polish........................................................................................................................ 42
Russian .....................................................................................................................44
Arabic.......................................................................................................................46
Japanese................................................................................................................... 48
A57A
1
CHAPTER 1: INTRODUCTION
1.1 BEFORE YOU START
Thank you for choosing our product. Before you start installing the
motherboard, please make sure you follow the instructions below:
î‚„ Prepare a dry and stable working environment with
sufficient lighting.
î‚„ Always disconnect the computer from power outlet
before operation.
î‚„ Before you take the motherboard out from anti-static
bag, ground yourself properly by touching any safely
grounded appliance, or use grounded wrist strap to
remove the static charge.
î‚„ Avoid touching the components on motherboard or the
rear side of the board unless necessary. Hold the board
on the edge, do not try to bend or flex the board.
î‚„ Do not leave any unfastened small parts inside the
case after installation. Loose parts will cause short
circuits which may damage the equipment.
î‚„ Keep the computer from dangerous area, such as heat
source, humid air and water.
î‚„ The operating temperatures of the computer should be
0 to 45 degrees Celsius.
1.2 P CACKAGE HECKLIST
Serial ATA Cable X2
Rear I/O Panel for ATX Case X1
User’s Manual X1
Fully Setup Driver DVD X1
Note: The package contents may be different due to area or your motherboard version.
Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU Socket FM1
AMD A-Series / E2-Series processors
AMD 64 Architecture enables 32 and 64 bit
computing
Chipset AMD A55
Super I/O
ITE 8728
Provides the most commonly used legacy
Super I/O functionality
Low Pin Count Interface
Environment Control initiatives
H/W Monitor
Fan Speed Controller
ITE's "Smart Guardian" function
Main
Memory
DDR3 DIMM Slots x 2
Max Memory Capacity 16GB
Each DIMM supports 512MB/
1GB/2GB/4GB/8GB DDR3
Dual Channel Mode DDR3 memory module
Supports DDR3 800/1066/1333/1600/1866
Registered DIMM and ECC DIMM is not supported
SATA II Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 specification compliant.
RAID 0,1,10 support
LAN RTL8111E / RTL8111F
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound VT1708B/ ALC662
5.1channels audio out
Supports HD Audio
PCI Express Gen2 x16 Slot x1 Supports PCI-E Gen2 x16, x4 expansion cards
PCI Express Gen2 x1 Slot x2 Supports PCI-E Gen2 p4-x1 expansion cards
Slots
PCI Slot x3 Supports PCI expansion cards
SATA Connector x6 Each connector supports 1 SATA device
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
S/PDIF out Connector x1 Supports digital audio out function
CPU Fan Header x1 CPU Fan power supply (with Smart Fan function)
System Fan Header x1 System Fan Power supply
On Board
Connectors
CMOS clear Header x1 Restore CMOS data to factory default
A57A
3
SPEC
USB2.0 Connector x2 Each connector supports 2 front panel USB2.0 ports
Printer Port Connector x1 Each connector supports 1 Printer port
Power Connector (24-Pin) x1 Connects to Power supply
Power Connector (4-Pin) x1 Connects to Power supply
Back Panel
I/O
PS/2 Keyboard x1
PS/2 Mouse x1
Serial Port x1
LAN port x1
USB2.0 Port x6
Audio Jack x3
Connects to PS/2 Keyboard
Connects to PS/2 Mouse
Connects to RS-232 Port
Connect to RJ-45 ethernet cable
Connect to USB2.0 devices
Provide Audio-In/Out and Mic. connection
Board Size 200 mm (W) x 295 mm (L) ATX
OS Support
Windows XP / Vista / 7
Biostar reserves the right to add or remove support
for any OS With or without notice.
1.4 R P CEAR ANEL ONNECTORS
P S /2
Mouse
P S/2
Ke yb oa r d
COM1 USB2 . 0X2US B2 .0 X2
L AN Line In /
S urround
Line O ut
M ic In 1/
B as s/ Ce nte r
US B2 .0 X2
Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
ATXPW R2
AUDIO1
RJ45USB1
KBMS1
COM1
USB2
USB1
PCI2
PCI3
PCI1
PEX16_1
PEX1_1
PEX1_2
DD R3_A1
DD R3_B1
CPU_FAN1
ATXPWR 1
F_U SB1
F_U SB2
J_P RINT1
F_ AUDIO1
J SPDIFOUT 1
JCMOS1
BIOS
LAN
Super
I/O
Codec
PANEL1
SYS_F AN 1
SATA2
SATA1
SATA4
SATA3
SATA6
SATA5
BAT1
AMD
A55
Note: represents the 1â– st pin.
A57A
5
CHAPTER 2: HARDWARE INSTALLATION
2.1 INSTALLING NIT CENTRAL PROCESSING U (CPU)
Step 1: Pull the lever toward direction A from the socket and then raise the
lever up to a 90-degree angle.
Step 2: Look for the white triangle on socket, and the gold triangle on
CPU should point towards this white triangle. The CPU will fit only
in the correct orientation.
Motherboard Manual
6
Step 3: Hold the CPU down firmly, and then close the lever toward direct
B to complete the installation.
Step 4: Put the CPU Fan on the CPU and buckle it. Connect the CPU
FAN power cable to the CPU_FAN1. This completes the
installation.
A57A
7
2.2 FAN HEADERS
These fan headers support cooling-fans built in the computer. The fan
cable and connector may be different according to the fan manufacturer.
Connect the fan cable to the connector while matching the black wire to
pin#1.
CPU_FAN1: CPU Fan Header
Pin
Assignment
1 Ground
2 +12V
3 FAN RPM rate
sense
41
4 Smart Fan
Control (By Fan)
SYS_FAN1: System Fan Header
Pin Assignment
1 Ground
2 +12V
1
3
3 FAN RPM
rate sense
Note:
CPU_FAN1, SYS_FAN1 support 4-pin and 3-pin head connectors. When connecting
with wires onto connectors, please note that the red wire is the positive and should be
connected to pin#2, and the black wire is Ground and should be connected to GND.
Motherboard Manual
8
2.3 INSTALLING SYSTEM MEMORY
A. DDR3 Modules
DDR3_A1
DDR3_B1
1. Unlock a DIMM slot by pressing the retaining clips outward. Align a
DIMM on the slot such that the notch on the DIMM matches the
break on the Slot.
2. Insert the DIMM vertically and firmly into the slot until the retaining
chip snap back in place and the DIMM is properly seated.
A57A
9
B. Memory Capacity
DIMM Socket
Location DDR3 Module Total Memory
Size
DDR3_A1 512MB/1GB/2GB/4GB/8GB
DDR3_B1 512MB/1GB/2GB/4GB/8GB Max is 16GB.
C. Dual Channel Memory installation
Please refer to the following requirements to activate Dual Channel function:
Install memory module of the same density in pairs, shown in the table
Dual Channel Status DDR3_A1 DDR3_B1
Disabled X O
Disabled O X
Enabled O O
(O means memory installed, X means memory not installed.)
The DRAM bus width of the memory module must be the same (x8 or
x16)
D. DDR Speed Support
Please refer to the following table for DDR speed reference:
# of DIMM per Channel # of Ranks per DIMM Max DDR Speed Grade
for 1.50V DIMM
1 of 1 UDIMM xR DDR3-1866
1 of 2 UDIMMs xR DDR3-1600 / DDR3-1333
Note:
xR: Single or double side memory moudule
Motherboard Manual
10
2.4 CONNECTORS AND S LOTS
SATA1~SATA6: Serial ATA Connectors
The motherboard has a PCI to SATA Controller with 6 channels SATA interface,
it satisfies the SATA 2.0 spec and with transfer rate of 3.0Gb/s.
Pin
Assignment
1 Ground
2 TX+
3 TX-
4 Ground
5 RX-
6 RX+
1 4 7
S A TA 2 4 6
1 3 5
S A TA S A T A
S A TA S A T A S A T A
7 Ground
ATXPWR2: ATX Power Source Connector
This connector provides +12V to CPU power circuit.
Pin
Assignment
1 +12V
2 +12V
3 Ground
1
2 3
4
4 Ground
A57A
11
ATXPWR1: ATX Power Source Connector
This connector allows user to connect 24-pin power connector on the ATX
power supply.
1
12
13
24
Pin Assignment Pin Assignment
13 +3.3V 1 +3.3V
14 -12V 2 +3.3V
15 Ground 3 Ground
16 PS_ON 4 +5V
17 Ground 5 Ground
18 Ground 6 +5V
19 Ground 7 Ground
20 NC 8 PW_OK
21 +5V 9 Standby Voltage+5V
22 +5V 10 +12V
23 +5V 11 +12V
24 Ground 12 +3.3V
Note:
Before you power on the system, please make sure that both ATXPWR1 and ATXPWR2
connectors have been plugged-in.
PCI1/PCI2/PCI3: Peripheral Component Interconnect Slots
This motherboard is equipped with 3 standard PCI slots. PCI stands for
Peripheral Component Interconnect, and it is a bus standard for expansion
cards. This PCI slot is designated as 32 bits.
PCI1
PCI2
PCI3
Motherboard Manual
12
PEX16_1: PCI-Express Gen2 x16 Slot
- PCI-Express 2.0 compliant.
- Maximum theoretical realized bandwidth of 8GB/s simultaneously per
direction, for an aggregate of 16GB/s totally.
- PCI-Express Gen2 supports a raw bit-rate of 5.0Gb/s on the data pins.
- 2X bandwidth over the PCI-Express 1.1 architecture.
PEX1_1/PEX1_2: PCI-Express Gen2 x1 Slots
- PCI-Express 2.0 compliant.
- Data transfer bandwidth up to 500MB/s per direction; 1GB/s in total.
- PCI-Express supports a raw bit-rate of 2.5Gb/s on the data pins.
PEX16_1
PEX1_1
PEX1_2
A57A
13
CHAPTER 3: HEADERS & JUMPERS SETUP
3.1 HOW TO S JETUP UMPERS
The illustration shows how to set up jumpers. When the jumper cap is
placed on pins, the jumper is “close”, if not, that means the jumper is
“open”.
Pin opened Pin closed Pin1-2 closed
3.2 DETAIL SETTINGS
PANEL1: Front Panel Header
This 16-pin connector includes Power-on, Reset, HDD LED, Power LED, and
speaker connection. It allows user to connect the PC case’s front panel switch
functions.
PWR_LED
RST
HLED
SPK
++
+
-
-
1
9 16
8
On/Off
Pin Assignment Function Pin Assignment Function
1 +5V 9 N/A
2 N/A 10 N/A N/A
3 N/A 11 N/A N/A
4 Speaker
Speaker
Connector
12 Power LED (+)
5 HDD LED (+) 13 Power LED (+)
6 HDD LED (-)
Hard drive
LED 14 Power LED (-)
Power LED
7 Ground 15 Power button
8 Reset control Reset button 16 Ground Power-on button
Produktspezifikationen
| Marke: | Biostar |
| Kategorie: | Hauptplatine |
| Modell: | A57A |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Biostar A57A benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Hauptplatine Biostar
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
Bedienungsanleitung Hauptplatine
- Hauptplatine Asus
- Hauptplatine Gigabyte
- Hauptplatine Sharkoon
- Hauptplatine MSI
- Hauptplatine Supermicro
- Hauptplatine NZXT
- Hauptplatine Asrock
- Hauptplatine ECS
- Hauptplatine EPoX
- Hauptplatine Evga
- Hauptplatine Intel
- Hauptplatine Abit
- Hauptplatine Elitegroup
- Hauptplatine Foxconn
Neueste Bedienungsanleitung fĂĽr -Kategorien-
15 Oktober 2024
7 Oktober 2024
5 Oktober 2024
4 Oktober 2024
4 Oktober 2024
2 Oktober 2024
27 September 2024
26 September 2024
24 September 2024
22 September 2024
