INSTALLATION AND OPERATING INSTRUCTIONS
for all Hydrocarbon Dual Temp Undercounter
UCRF Refrigerator/Freezer Models
3779 CHAMPION BLVD, WINSTON-SALEM, NC 27105
Phone: (888) 845-9800 | Fax: (800) 253-5168 | Web: beverage-air.com
809-175A Rev. A. 02/20/2023 SEE BACK COVER FOR
WARRANTY REGISTRATION
User Manual for UCRF Refrigerator Freezer Beverage Air
Rev. 02/23Beverage Air2
WELCOME
Contents
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Important Information . . . . . . . . . . . . . . . . . . . . . . . 5
Product Information . . . . . . . . . . . . . . . . . . . . . . . . 6
Clearance and Placement . . . . . . . . . . . . . . . . . . . . . 7
Unpacking and Set Up . . . . . . . . . . . . . . . . . . . . . . . 8
Shelf Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Using The Unit - Danfoss Controller . . . . . . . . . . . . . . . 11
Sequence of Operations Refrigerator Section . . . . . . 12
Sequence of Operations - Freezer Section . . . . . . . . 16
Using The Unit - Eliwell Controller 20. . . . . . . . . . . . . . . .
Sequence of Operations Refrigerator Section . . . . . . 21
Cleaning and Maintenance . . . . . . . . . . . . . . . . . . . . 24
Condenser Cleaning 25. . . . . . . . . . . . . . . . . . . . . . . . .
Methods For Cleaning Stainless Steel 26. . . . . . . . . . . . . .
Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
For The Service Tech - R290 . . . . . . . . . . . . . . . . . . . 28
For The Service Tech - Wiring Diagrams . . . . . . . . . . . . 29
Limited Warranty 32. . . . . . . . . . . . . . . . . . . . . . . . . .
Limited Warranty (continued) . . . . . . . . . . . . . . . . . . 33
Important Information
• PLEASE READ THESE INSTRUCTIONS CAREFULLY
BEFORE INSTALLING OR USING, IF RECOMMENDED
PROCEDURES ARE NOT FOLLOWED, WARRANTY
CLAIMS MAY BE DENIED.
• Your warranty registration information is located with
this manual. Please complete the card and submit it to
Beverage Air within TEN days of installation. Failure
to properly register equipment may limit or void the
warranty.
• Beverage Air reserves the right to change
specications and product design without
notice. Such revisions do not entitle the buyer to
corresponding changes, improvements, additions, or
replacements for previously purchased equipment.
Congratulations on your purchase of Beverage-Air food
service equipment. Every employee welcomes you to the
family of satised Beverage-Air customers.
From the earliest stages of production design, to focused
steps in fabrication and assembly, rigid standards of
quality are maintained by our sta of skilled employees.
Beverage-Air strives to supply superior products through
strict quality control guidelines exceeding industry
standards, this means that each unit, given the proper
maintenance will provide years of trouble free experience
to its owner.
Additionally, Beverage-Air food service equipment has
one of the best warranties in the food service industry,
and backed by a professional sta of service technicians
across the country.
We thank you for your choice and condence in Beverage-
Air Equipment.
For part inquiries or orders please call our Technical
Service Department at (800) 684-1199. 8:00 AM to 5:00
PM EST.
User Manual for UCRF Refrigerator Freezer Beverage Air
Rev. 02/23 Beverage Air 3
SAFETY
This appliance has been designed with your safety in mind. It has many features to keep you from being harmed. However,
safe operation and maintenance are your responsibilities. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Use: When using this unit, please:
• Move it carefully. If on casters be sure the casters
do NOT run over the power cord.
• Lock the casters when in use.
• Seek help. This machine is heavy! Be sure to move
with enough help to avoid tipping or dropping the
cabinet.
• Prevent children from playing in or on the cabinet.
Persons unable to use this product must be
prevented access.
• Follow all instructions. There are many safety
labels and directions on the unit. Heed them.
• Watch your ngers. There may be pinch points near
the door hinges.
Maintenance
Do NOT:
• Clean a frozen evaporator with a sharp object
• Clean a dirty condenser with a sharp object.
• Store gasoline, kerosene or any other ammable
material near the cabinet.
Do ALWAYS
• Use a Beverage Air recommended technician certied
to repair R290 equipment.
• Use ONLY Beverage Air factory service parts. Use of
non OEM parts can be dangerous because of the design
changes needed to safely use R290.
Observe the and Caution Warning notices. They are indicators of
important safety information. Keep this manual for future reference.
Important Information to Add
Record the model number, serial number and the date of installation here for future reference. The model and serial
numbers are on the unit's serial number dataplate, which is located on the left inside wall.
Model Number
Serial Number
Date of Installation
Purchased From
CAUTION
WARNING
CAUTION
CAUTION
