FOR INSTALLERS PAG. 12
FOR THE USER PAG. 15
TYPES OF COOKER HOBS PAG. 76
ENGLISH
12
BEFORE USING YOUR COOKER HOB
RECOMMENDED ENVIRONMENTAL SAFEGUARDS
Before you use this cooker hob we suggest that you read the
instructions carefully and keep them for future consultation.
Keep packing material (plastic bags, styrofoam blocks, etc...) out of
the reach of children as they can be dangerous.
Make sure the cooker hob is intact and has not undergone damage
during shipment.
Make sure the installation and gas and/or electric connections are
made by a qualified expert according to the manufacturers
instructions and in compliance with the local regulations in effect.
Any exhaust hoods installed over the cooker hob should be
positioned at the height indicated (pict. A).
Packing: the packing material can be recycled and is marked with the
recycle symbol. Pieces of styrofoam, if any, should not be disposed of
carelessly. Dispose of this waste material at local dumps.
Product: the cooker hob is made of materials suitable for recycling.
Dispose of it in respect of the local regulations for waste disposal, after
making sure it cannot cause any damage. We recommend cutting the
power cable.
FOR INSTALLERS
TECHNICAL INFORMATION
Installation of BUILT-IN UNIT
To install built-in cooker hobs make an opening in the top of the cabi-
net with measurements A-B (pict. 1) as indicated in mm. in the table
below:
For the flush-mount version of the hobs (model 7043, 7044, 7045)
please refer to the specific instructions inside the box.
Note: Before installing make sure the local gas distribution system (type
and pressure of the gas) and settings of the cooker hob are compatible
(see rating plate).
Before installing the unit, remove any protective film
Any laminate on the walls of the cabinet or adjacent
(pict. A)
B A R
29x50 cooker hobs 480 270
59x50 cooker hobs 480 570
76x50 Mod. 7024V 480 740
86x50 cooker hobs 480 840
76x50 Mod. 7065V 480 570/740
79x50 cooker hobs 480 770
116x50 cooker hobs 480 1140
Rondò Ø 52 units diam. 500 /
79x50 cooker hobs Soft 480 770 135
92x54 cooker hobs 520 900
Cooker hobs angolare (fig. 1A)
Dimensions of burner
unit and counter
(fig. 1)
(fig. 2)
480330
810
480 330
810
610
610
20x45∞
200x
45∞
(fig. 1A)
B
A
R
14
by 50°C.
Before connecting to the power mains make sure:
The mains voltage corresponds to the rating of the unit (see rating
plate).
The modulating valve and domestic wiring can withstand the charge
of the appliance (see rating plate)
The outlet or omni pole switch used for connection are readily acces-
sible to the appliance installed.
Our cooker hobs comply with EEC Directive 89/336 on the prevention
and elimination of radio interference.
Appliances must always be grounded. Our company is not responsible
for failure of the grounding system to function and for connections that
do not comply with the provisions of the laws in effect.
NATIONAL REFERENCE STANDARDS
Connection to gas supply, gas connection and ventilation of rooms must
be carried out in accordance with local regulations.
REGULATION OF MINIMUM
Our taps are suitable for all types of gas and are regulated at the mini-
mum as follows:
1. Light the burner and turn the knob to the minimum position. If the
flame should go out, proceed as follows:
a) light the burner at maximum capacity (large flame)
b) remove the knob
c) introduce a small screwdriver in hole B on the shaft of the tap (pict.
6) and unscrew the adjustment screw by two turns. On some units
hole B is on the right or left of the tap (pict. 6/B and pict. 6/C).
NOTE: on some units, to access regulation hole B it may be necessary
to unscrew lock ring C (pict. 6/C). Depending on the type, the minimum
adjustment screw may be on the right or left of the tap.
d) replace the knob and turn to the minimum position (small flame)
e) remove the knob and proceed as in 3.
2. Remove the knob from the tap
3. Introduce a small screwdriver in hole B (pict. 6) and tighten or loo-
sen the adjustment screw (taking care not to turn the shaft of the
tap) until the burner flame is properly adjusted at the minimum.
The gas supply is correct when the tip of the flame reaches a length of
~ 4 mm at the minimum.
Check that when passing quickly from the maximum position to the
minimum the flame does not go out.
REPLACEMENT OF NOZZLES
The burners are adaptable to different types of gas by replacing only the
nozzles for the type of gas used (see data table). To access the nozzle,
simply remove the cap and flame-breaker.
To change the nozzles, use a no. 7 socket wrench (pict. 7).
IMPORTANT!!!
In case of appliances installed previously, always disconnect the power
before performing any operation.
(pict. 6/B)
(pict. 6)
(pict. 6/C)
(pict. 6/A)
(pict. 7)Nozzle
