Instructions and installation
manual
MODELS:
BSGH95-ANZ / BSGH75-ANZ
BSGH64-ANZ / BSGH32-ANZ
BSGH30-ANZ
PLEASE READ THIS MANUAL BEFORE
INSTALLING THE COOKTOP.
COD. 04067IR 26.02.2013
2
Natural U-LPG
1 Ultra rapid gas burner/WOK 14.5 MJ/h 12.6 MJ/h
2 Rapid gas burner 12.0 MJ/h 10.4 MJ/h
3 Semirapid reduced gas burner 5.4 MJ/h 4.9 MJ/h
4 Semirapid gas burner 7.1 MJ/h 6.3 MJ/h
5 Auxiliary gas burner 4.1 MJ/h 3.6 MJ/h
6 Pan stands support 2F
7 Pan stands support 1F
8 Burner n° 2 control knob
9 Burner n° 5 control knob
10 Burner n° 1 control knob
11 Burner n° 3 control knob
12 Burner n° 4 control knob
Attention: this appliance has been manufactured for domestic use only. Do not modify this
appliance.
DESCRIPTION OF COOKTOP
5
9
9
6
8
8
10
6
7
7
10 1211
To use the WOK pan support on ultra rapid
gas burner only.
Put it on the ultra rapid pan support and
make sure of the stability (see fig. A).
Fig. A
9
6
8
6
7
12 11 10
3
USE
FIG. 1 FIG. 2
1) BURNERS
A diagram is screen-printed above each knob on the
front panel. This diagram indicates to which burner
the knob in question corresponds. After having
opened the gas mains or gas bottle tap, light the
burners as described below:
- automatic electrical ignition
Push and turn the knob corresponding to the
required burner in an anticlockwise direction until it
reaches the full on position (large flame fig. 1), then
depress the knob.
- Lighting burners equipped with flame failure
device
The knobs of burners equipped with flame failure
device must be turned in an anticlockwise direction
until they reach the full on position (large flame fig. 1)
and come to a stop. Now depress the knob in
question and repeat the previously indicated
operations.
Keep the knob depressed for about 10 seconds once
the burner has ignited.
Note: you are advised not to try and light a
burner if the flame divider (burner Cap) is not
correctly placed
HOW TO USE THE BURNERS
Bear in mind the following indications in order to
achieve maximum efficiency with the least possible
gas consumption:
- Use adequate pans for each burner (consult the
following table and fig. 2).
- When the pan comes to the boil, set the knob to
the reduced rate position (small flame fig. 1).
- Always place a lid on the pans.
- Use only pan with a flat bottom.
WARNINGS:
- Burners with flame failure device may only be
ignited when the relative knob has been set to
the Full on position (large flame fig. 1).
- Matches can be used to ignite the burners in a
blackout situation.
- Never leave the appliance unattended when the
burners are being used. Make sure there are no
children in the near vicinity. Particularly make
sure that the pan handles are correctly
positioned and keep a check on foods
requiring oil and grease to cook since these
products can easily catch fire.
- The appliance must not be used by people
(including children) with impaired mental or
physical capacities, or without experience of
using electrical devices, unless supervised or
instructed by an expert adult responsible for
their care and safety. Children should not be
allowed to play with the equipment.
- Never use aerosols in the vicinity of this appliance
while it is in operation.
- Should a crack appear on the surface of the glass,
disconnect the appliance from the electricity
supply immediately.
- Do not place pans with an unstable or deformed
bottom on the burner, as these may tip or spill their
contents, causing accidents.
- Do not store or use flammable liquids or items
in the vicinity of the cooktop.
- Do not use the hob as a work surface.
- This product is not to be installed in marine
crafts, caravans, or mobile homes.
- Containers wider than the unit are not
recommended.
- Avoid scraping the pans on the glass surface,
as the surface may become scratched.
- Do not modify this appliance.
Burners
Power ratings Pan Ø
in cm
Natural U-LPG
Ultra rapid/WOK 14.5 MJ/h 12.6 MJ/h 24 ÷ 26
Rapid 12.0 MJ/h 10.4 MJ/h 20 ÷ 22
Semirapid reduced 5.4 MJ/h 4.9 MJ/h 16 ÷ 18
Semirapid 7.1 MJ/h 6.3 MJ/h 16 ÷ 18
Auxiliary 4.1 MJ/h 3.6 MJ/h 10 ÷ 14
In the event of the Burner flames being accidentally
extinguished, turn off the burner control and do not
attempt to re-ignite the burner for a least 1 minute.
