HOBS
USER INSTRUCTIONS
CANDY HOOVER GROUP S.R.L. • Via Comolli 16 • 20861 Brugherio (MB) Italy
GB 02
![](https://manualstech.ams3.cdn.digitaloceanspaces.com/html/nl/baumatic/bhig620x/html/bg2.png)
02 GB
SAFETY INSTURUCTIONS
We recommend you keep the instructions for
installation and use for later reference, and before
installing the hob, note its serial number in case
you need to get help from the after sales service.
WARNING: the appliance and its accessible parts
become hot during use. Care should be taken to
avoid touching heating elements. Children under
8 years of age must be kept away from the
appliance unless they are continuously
supervised.
WARNING: use only hob guards designed by the
Manufacturer of the cooking appliance or
indicated by the Manufacturer of the appliance in
the instructions for use as suitable or hob guards
incorporated in the appliance. The use of
inappropriate guards can cause accidents.
WARNING: unattended cooking on a hob with fat
or oil can be dangerous and may result in fire.
NEVER try to extinguish a fire with water, but
switch off the appliance and then cover flame e.g.
with a lid or a fire blanket.
WARNING: danger of fire: do not store items on
the cooking surfaces.
WARNING: if the surface is cracked, do not touch
the glass and switch off the appliance to avoid the
possibility of electric shock.
This appliance can be used by children aged from
8 years and above and people with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved. Children should be supervised
to ensure that they do not play with the appliance.
Cleaning and user maintenance shall not be
made by children without supervision.
CAUTION: the cooking process must be
supervised. A short term cooking process has to
be supervised continuously.
It is strongly recommended to keep children away
from the cooking zones while they are in operation
or when they are switched off, so long as the
residual heat indicator is on, in order to prevent
the risks of serious burns.
This appliance is not intended to be operated by
means of an external timer or separate remote
control system.
If present do not to stare into halogen lamp hob
elements.
Connect a plug to the supply cable that is able to
bear the voltage, current and load indicated on the
tag and having the earth contact. The socket must
be suitable for the load indicated on the tag and
must be having the earth contact connected and
in operation. The earth conductor is yellow-green
in color. This operation should be carried out by a
suitably qualified professional. In case of
incompatibility between the socket and the
appliance plug, ask a qualified electrician to
substitute the socket with another suitable type.
The plug and the socket must be conformed to
the current norms of the installation country.
Connection to the power source can also be
made by placing an omnipolar breaker between
the appliance and the power source that can bear
the maximum connected load and that is in line
with current legislation.
The yellow-green earth cable should not be
interrupted by the breaker. The socket or
omnipolar breaker used for the connection
should be easily accessible when the appliance is
installed.
The disconnection may be achieved by having
the plug accessible or by incorporating a switch in
the fixed wiring in accordance with the wiring
rules.
If the supply cord is damaged, it must be replaced
by Manufacturer, its service agent or similarly
qualified people in order to avoid a hazard. The
earth conductor (yellow-green) must be longer
than 10 mm on the terminal block side. The
internal conductors section should be
appropriate to the power absorbed by the hob
(indicated on the tag). The type of power cable
must be HO5V2V2-F.
Do not put metallic objects such as knives, forks,
spoons or lids on the hob. They could heat up.
Aluminum foil and plastic pans must not be
placed on heating zones.
After every use, some cleaning of the hob is
necessary to prevent the build-up of dirt and
grease. If left, this is recooked when the hob is
used and burns giving off smoke and unpleasant
smells, not to mention the risks of fire
propagation.
Never use a steam or high pressure spray to
clean the appliance.
Do not touch the heat zones during operation or
for a while after use.
Never cook food directly on the glass ceramic
hob.
Always use the appropriate cookware.Always
place the pan in the center of the unit that you are
cooking on.
Do not place anything on control panel.
Do not use the hob as a working surface.
Do not use the surface as a cutting board.
Do not store heavy items above the hob. If they
drop onto the hob, they may cause damage.
Do not use the hob for storage of any items.
Do not slide cookware across the hob.
![](https://manualstech.ams3.cdn.digitaloceanspaces.com/html/nl/baumatic/bhig620x/html/bg3.png)
03 GB
The hob may be installed in any worktop which is heat resistant to a
temperature of 100°C, and has a thickness of 25-45 mm. The
dimensions of the insert to be cut out of the worktop are in shown in
Figure 2.
When there is an accessible space between the built-in hob and the
cavity below, a dividing wall made of insulating material should be
inserted (wood or a similar material) (Figure 3).
If the Hob is fitted next to a cabinet on either side, the distance between
the Hob and the cabinet must be at least 15 cm ; while(see Figure 4)
the distance between the hob and the rear wall must be at least .70 mm
The distance between the hob and any other unit or appliance above it
(e.g.An extractor hood) must be no less than 70 cm .(Figure 4)
Metal objects in the drawer may reach high temperatures due to
air recirculation. It is therefore recommended to use an
intermediate wood panel.
Important - The diagram in figure 1 shows how the sealant should
be applied.
The Hob unit is fitted by attaching the Fixing Clamps supplied, using
the holes at the base of the unit.
If a hob of 60 cm is fitted above an oven which is not equipped with fan
cooling system it is recommended that openings are created within the
built in furniture to ensure correct air circulation.
The size of these openings must be at least 300 cm2 and placed as
shown in Figure 5.
When a 75 cm hob is fitted over a built in oven, the latter must be fan
cooled.
1.1 BUILDING IN
1.2. SUITABLE LOCATION
This appliance must be installed in accordance with the regulations in
force and only used in a well ventilated space. Read the instructions
before installing or using this appliance.
A gas-powered cooking appliance produces heat and humidity in the
area in which it is installed. For this reason you should ensure good
ventilation either by keeping all natural air passages open or by
installing an extractor hood with an exhaust flue. Intensive and
prolonged use of the appliance may require extra ventilation, such as
the opening of a window or an increase in speed of the electric fan, if
you have one.
If a hood can not be installed, an electric fan should be fitted to an
outside wall or window to ensure that there is adequate ventilation.
The electric fan should be able to carry out a complete change of air in
the kitchen 3-5 times every hour. The installer should follow the
relevant national standards.
2. ELECTRICAL CONNECTION (FOR U.K. ONLY)
Warning - this appliance must be earthed
This appliance is designed for domestic use only. Connection to the main
supply must be made by a competant electrician, ensuring that all current
regulations concerning such installations are observed.
The appliance must only be connected to a suitably rated spur point, a
3 pin 13 amp plug/socket is not suitable. A double pole switch must be
provided and the circuit must have appropriate fuse protection.
Further details of the power requirement of the individual product will
be found in the users’ instruction and on the appliance rating plate. In
the case of built-in product you are advised, should you wish to use a
longer cable than the one supplied, that a suitably rated heat resistant
type must be used.
The wiring must be connected to the mains supply as follows:
CONNECT TO SPUR TERMINAL
Green & Yellow Wire Earth Connection
Blue Wire Neutral Connection
Brown Wire Live Connection
Note: We do not advocate the use of earth leakage devices with
electric cooking appliances installed to spur points because of the
«nuisance tripping» which may occur. You are again reminded that the
appliance must be correctly earthed, the manufacturer declines any
responsibility for any event occurring as a result of incorrect electrical
installation.
2.1. ELECTRICAL CONNECTION
Check the data on the rating plate, located on the outside of the unit, to
ensure that the supply and input voltage are suitable.
Before connection, check the earthing system.
By Law, this appliance must be earthed. If this regulation is not complied
with, the Manufacturer will not be responsible for any damage caused to
persons or property. If a plug is not already attached, fit a plug
appropriate to the load indicated on the rating plate. The earth wire is
coloured yellow/green. The plug should always be accessible.
Where the Hob is connected direct to the electricity supply, a circuit
breaker must be fitted.
If the power supply cord is damaged this is to be replaced by a qualified
engineer so as to prevent any potential risk.
The earth wire ( green and yellow coloured ) must be at least 10 mm
longer than the live and neutral wires.
The section of the cable used must be of the correct size in relation to
the absorbed power of the hob.
Please check rating plate for the power details and ensure that the
power supply cord is of the type 3x0.75 mm² H05 V2V2-F.
LIVE
EARTH
NEUTRAL
L
N
Power Cable
Brown Wire
Green/Yellow Wire
Blue Wire
Mains Supply
If an appliance is not fitted with a supply cord and a plug, or with other
means for disconnection from the supply mains having a contact
separation in all poles that provide full disconnection under overvoltage
category III conditions, the instructions shall state that means for
disconnection must be incorporated in the fixed wiring in accordance with
the wiring rules.
1. INSTRUCTIONS FOR THE INSTALLER
INSTALLING A DOMESTIC APPLIANCE CAN BE A COMPLICATED OPERATION WHICH IF NOT CARRIED OUT CORRECTLY, CAN SERIOUSLY
AFFECT CONSUMER SAFETY. IT IS FOR THIS REASON THAT THE TASK SHOULD BE UNDERTAKEN BY A PROFESSIONALLY QUALIFIED
PERSON WHO WILL CARRY IT OUT IN ACCORDANCE WITH THE TECHNICAL REGULATIONS IN FORCE. IN THE EVENT THAT THIS ADVICE IS
IGNOREDAND THE INSTALLATION IS CARRIED OUT BY AN UNQUALIFIED PERSON, THE MANUFACTURER DECLINES ALLRESPONSIBILITY
FORANY TECHNICALFAILURE OF THE PRODUCT WHETHER OR NOT ITRESULTS IN DAMAGETO GOODS ORINJURY TO INDIVIDUALS.
These instructions are for qualified personnel, installation of
equipment must be in line with the relevant national standard. (For
U.K. only: by law the gas installation\commissioning must be
carried out by a "Gas Safe" installer)
All work must be carried out with the electricity supply disconnected.
The rating plate on the hob shows the type of gas with which it is
designed to be used. Connection to the mains gas supply or gas
cylinder should be carried out after having checked that it is regulated
for the type of gas with which it will be supplied. If it is not correctly
regulated see the instructions in the following paragraphs to change
gas setting.
For liquid gas (cylinder gas) use pressure regulators which comply
with the relevant national standards.
Use only pipes,washers and sealing washers which comply with the
relevant national standards.
For some models a conic link is furnished to outfit for the installation in
the countries where this type of link is obligatory; in picture 8 it is
pointed out how to recognize the different types of links (CY =
cylindrical, CO = conic). In every case the cylindrical part of the link
has to be connected to the hob.
When connecting the hob to the gas supply via use offlexible hoses
please ensure that the maximum distance covered by the hose does
not exceed 2 metres.
The flexible tube shall be fitted in such a way that it cannot come into
contact with a moveable part of the housing unit (e.g. a drawer) and does
not pass through any space where it may become crushed/ kinked or
damaged in any way.
To prevent any potential damage to the hob please carry out the
installation following this sequence (picture 6):
1)As illustrated, assemble parts in sequence:
A: 1/2 Male Adaptor Cylindirical
B: 1/2 Seal
C: 1/2 Female Gas Adaptor Conical-Cylindirical or
Cylindirical-Cylindirical
2.2. GAS CONNECTION
Produktspezifikationen
Marke: | Baumatic |
Kategorie: | Fornuis |
Modell: | BHIG620X |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Baumatic BHIG620X benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Fornuis Baumatic
![Baumatic](/images/pdf_free.png)
5 September 2024
![Baumatic](/images/pdf_free.png)
13 August 2024
![Baumatic](/images/pdf_free.png)
11 August 2024
![Baumatic](/images/pdf_free.png)
7 August 2024
![Baumatic](/images/pdf_free.png)
7 August 2024
![Baumatic](/images/pdf_free.png)
5 August 2024
![Baumatic](/images/pdf_free.png)
5 August 2024
![Baumatic](/images/pdf_free.png)
4 August 2024
![Baumatic](/images/pdf_free.png)
4 August 2024
![Baumatic](/images/pdf_free.png)
4 August 2024
Bedienungsanleitung Fornuis
- Fornuis Samsung
- Fornuis AFK
- Fornuis Infiniton
- Fornuis Clatronic
- Fornuis Domo
- Fornuis Emerio
- Fornuis Ernesto
- Fornuis Tristar
- Fornuis Manta
- Fornuis Medion
- Fornuis Nedis
- Fornuis SilverCrest
- Fornuis Hanseatic
- Fornuis Panasonic
- Fornuis Clas Ohlson
- Fornuis LG
- Fornuis Adler
- Fornuis Bestron
- Fornuis Camry
- Fornuis Guzzanti
- Fornuis MX Onda
- Fornuis Princess
- Fornuis Trisa
- Fornuis Bosch
- Fornuis AEG
- Fornuis Ambiano
- Fornuis Ardes
- Fornuis Asko
- Fornuis Siemens
- Fornuis ATAG
- Fornuis Bauknecht
- Fornuis Bifinett
- Fornuis Buffalo
- Fornuis Caso
- Fornuis Concept
- Fornuis Electrolux
- Fornuis Ellrona
- Fornuis Fagor
- Fornuis Gaggenau
- Fornuis Gorenje
- Fornuis Jata
- Fornuis Klarstein
- Fornuis Koenic
- Fornuis Küppersbusch
- Fornuis Miele
- Fornuis Proficook
- Fornuis Rommelsbacher
- Fornuis Severin
- Fornuis Teka
- Fornuis Whirlpool
- Fornuis Bomann
- Fornuis Essentiel B
- Fornuis First Austria
- Fornuis Hendi
- Fornuis Korona
- Fornuis Listo
- Fornuis OK
- Fornuis Russell Hobbs
- Fornuis Steba
- Fornuis Taurus
- Fornuis Tefal
- Fornuis Vox
- Fornuis IKEA
- Fornuis ECG
- Fornuis König
- Fornuis Bush
- Fornuis Thomson
- Fornuis Amica
- Fornuis BEKO
- Fornuis Blaupunkt
- Fornuis Boretti
- Fornuis Cuisinart
- Fornuis Eldom
- Fornuis Eta
- Fornuis Fritel
- Fornuis Grundig
- Fornuis Heinner
- Fornuis Hotpoint
- Fornuis Inventum
- Fornuis Kenwood
- Fornuis KitchenAid
- Fornuis Schneider
- Fornuis Sharp
- Fornuis Smeg
- Fornuis Tomado
- Fornuis Waring Commercial
- Fornuis Wilfa
- Fornuis Witt
- Fornuis WMF
- Fornuis Dometic
- Fornuis Outwell
- Fornuis Alpina
- Fornuis Ardo
- Fornuis Aspes
- Fornuis Balay
- Fornuis Blomberg
- Fornuis Scandomestic
- Fornuis Brandt
- Fornuis Candy
- Fornuis Castor
- Fornuis Constructa
- Fornuis Corberó
- Fornuis Curtiss
- Fornuis Daewoo
- Fornuis Edesa
- Fornuis Eurotech
- Fornuis Everglades
- Fornuis Exquisit
- Fornuis Finlux
- Fornuis GE
- Fornuis Haier
- Fornuis High One
- Fornuis Hisense
- Fornuis Hoover
- Fornuis Hotpoint-Ariston
- Fornuis Iberna
- Fornuis Ignis
- Fornuis Bartscher
- Fornuis Indesit
- Fornuis Juno
- Fornuis Kelvinator
- Fornuis Bertazzoni
- Fornuis Maytag
- Fornuis Midea
- Fornuis Caple
- Fornuis Neff
- Fornuis Nordmende
- Fornuis PKM
- Fornuis Privileg
- Fornuis Progress
- Fornuis Rex
- Fornuis Rommer
- Fornuis ETNA
- Fornuis Scholtès
- Fornuis Frigidaire
- Fornuis Svan
- Fornuis Techwood
- Fornuis Thor
- Fornuis V-ZUG
- Fornuis Vestel
- Fornuis Vestfrost
- Fornuis Junker
- Fornuis Zanker
- Fornuis Zanussi
- Fornuis KKT Kolbe
- Fornuis Zerowatt
- Fornuis Leonard
- Fornuis M-System
- Fornuis Oranier
- Fornuis Pelgrim
- Fornuis Philco
- Fornuis Respekta
- Fornuis Rosières
- Fornuis Thermador
- Fornuis Eurom
- Fornuis Altus
- Fornuis Arçelik
- Fornuis Continental Edison
- Fornuis Hyundai
- Fornuis Kernau
- Fornuis Orava
- Fornuis Tesla
- Fornuis Livoo
- Fornuis Imperial
- Fornuis Elica
- Fornuis Sencor
- Fornuis DeLonghi
- Fornuis Biltema
- Fornuis Element
- Fornuis Eico
- Fornuis Ariete
- Fornuis Efbe-Schott
- Fornuis Franke
- Fornuis Kalorik
- Fornuis Scarlett
- Fornuis Tripp Lite
- Fornuis Cecotec
- Fornuis Zephir
- Fornuis Husqvarna
- Fornuis Wolkenstein
- Fornuis Gemini
- Fornuis Frilec
- Fornuis Foster
- Fornuis Opera
- Fornuis Silverline
- Fornuis Cramer
- Fornuis Binatone
- Fornuis Novy
- Fornuis Airforce
- Fornuis Airlux
- Fornuis Cata
- Fornuis Cylinda
- Fornuis De Dietrich
- Fornuis Dominox
- Fornuis Elba
- Fornuis Falcon
- Fornuis Falmec
- Fornuis Faure
- Fornuis Hansa
- Fornuis Leisure
- Fornuis Lofra
- Fornuis MPM
- Fornuis Stoves
- Fornuis Thermex
- Fornuis UPO
- Fornuis Logik
- Fornuis Team
- Fornuis GYS
- Fornuis Veripart
- Fornuis Thetford
- Fornuis Dacor
- Fornuis Bluesky
- Fornuis Heller
- Fornuis Orima
- Fornuis Proline
- Fornuis Dimplex
- Fornuis Kayoba
- Fornuis Matrix
- Fornuis Cambridge
- Fornuis Mora
- Fornuis Westinghouse
- Fornuis Eccotemp
- Fornuis Wolf
- Fornuis Amana
- Fornuis Arthur Martin-Electrolux
- Fornuis Gram
- Fornuis NextBase
- Fornuis Vivax
- Fornuis Omega
- Fornuis Profilo
- Fornuis Sauber
- Fornuis Zelmer
- Fornuis Kleenmaid
- Fornuis Lamona
- Fornuis Limit
- Fornuis Meireles
- Fornuis Breville
- Fornuis Kogan
- Fornuis Navitel
- Fornuis Hoover-Helkama
- Fornuis New Pol
- Fornuis BORA
- Fornuis Crosley
- Fornuis Xblitz
- Fornuis Danby
- Fornuis Viking
- Fornuis Vedette
- Fornuis Sogo
- Fornuis Tracer
- Fornuis Ariston Thermo
- Fornuis Mellerware
- Fornuis Proctor Silex
- Fornuis Signature
- Fornuis RCA
- Fornuis Bellini
- Fornuis Swan
- Fornuis AYA
- Fornuis Fisher & Paykel
- Fornuis Esatto
- Fornuis Drew & Cole
- Fornuis Orbegozo
- Fornuis Napoleon
- Fornuis Ilve
- Fornuis Furrion
- Fornuis Izzy
- Fornuis CDA
- Fornuis Flavel
- Fornuis Saturn
- Fornuis Cadac
- Fornuis Eurochef
- Fornuis Berg
- Fornuis Defy
- Fornuis Duronic
- Fornuis Edilkamin
- Fornuis Emax
- Fornuis Firefriend
- Fornuis Fratelli Onofri
- Fornuis ILive
- Fornuis Jocel
- Fornuis Kenmore
- Fornuis La Germania
- Fornuis Lacanche
- Fornuis Magic Chef
- Fornuis Marynen
- Fornuis Rangemaster
- Fornuis Roadeyes
- Fornuis Sirius
- Fornuis Solitaire
- Fornuis SPT
- Fornuis Technika
- Fornuis Tecnolux
- Fornuis Weasy
- Fornuis WLA
- Fornuis BLANCO
- Fornuis Parmco
- Fornuis Hatco
- Fornuis Avanti
- Fornuis Kunft
- Fornuis Kucht
- Fornuis Becken
- Fornuis Wells
- Fornuis Nevir
- Fornuis JennAir
- Fornuis Rinnai
- Fornuis Winia
- Fornuis BlueStar
- Fornuis Romo
- Fornuis Girmi
- Fornuis Ravanson
- Fornuis Fulgor Milano
- Fornuis ZLine
- Fornuis K&H
- Fornuis Creda
- Fornuis Arctic Cooling
- Fornuis Zavor
- Fornuis Barazza
- Fornuis Artusi
- Fornuis MSR
- Fornuis Vulcan
- Fornuis Glem Gas
- Fornuis Nemco
- Fornuis Nesco
- Fornuis Nutrichef
- Fornuis Cuckoo
- Fornuis Sôlt
- Fornuis Chef
- Fornuis Khind
- Fornuis Koblenz
- Fornuis Promis
- Fornuis Hiberg
- Fornuis Gasmate
- Fornuis Companion
- Fornuis LERAN
- Fornuis Belling
- Fornuis Cookology
- Fornuis Summit
- Fornuis Forge Adour
- Fornuis Linarie
- Fornuis Mabe
- Fornuis Lafe
- Fornuis Esmaltec
- Fornuis Euro Appliances
- Fornuis Capital
- Fornuis PITT
- Fornuis Electroline
- Fornuis Café
- Fornuis Porter & Charles
- Fornuis Aga
- Fornuis Jenn-Air
- Fornuis New World
- Fornuis Brixton
- Fornuis Belion
- Fornuis Tisira
- Fornuis Verona
- Fornuis Simfer
- Fornuis Triomph
- Fornuis Pando
- Fornuis Kluge
- Fornuis HomeCraft
- Fornuis La Cornue
Neueste Bedienungsanleitung für -Kategorien-
![Bertazzoni](/images/pdf_free.png)
8 September 2024
![Bertazzoni](/images/pdf_free.png)
8 September 2024
![GE](/images/logos/ge.png)
8 September 2024
![Küppersbusch](/images/logos/kuppersbusch.png)
8 September 2024
![Frigidaire](/images/logos/frigidaire.png)
8 September 2024
![Viking](/images/pdf_free.png)
8 September 2024
![Arçelik](/images/pdf_free.png)
8 September 2024
![Rosières](/images/pdf_free.png)
8 September 2024
![Blomberg](/images/pdf_free.png)
8 September 2024
![BEKO](/images/logos/beko.png)
8 September 2024
