ENDaily Reference Guide

THANK YOU FOR BUYING A BAUKNECHT PRODUCT.

In order to receive a more complete assistance, please

FIRST TIME USE

Before using the appliance carefully read

Safety and Installation Instructions. More information about your

product available on website: docs.bauknecht.eu

After installation, please remember to remove all transport protection

parts from the dishwasher.

SETTING MENU

1. Switch on the appliance by pressing the button.ON-OFF

2. Hold the Settings (Half Load ) button for 3 seconds, until you hear

a beep and the display shows „SEt”.

3. After one second the rst available setting (letter „h”) will be displayed.

4. Press PREVIOUS /NEXT to scroll through the list of available settings

(see table below), then press START/Pause to view and change the

value of the currently selected setting.

5. Press PREVIOUS /NEXT to change the value, then press START/Pause

to save the new value and return to the main menu.

6. To change another setting, repeat points 4 and 5.

7. Press or wait 30 seconds to exit the menu.ON-OFF

LETTER SETTING VALUES

(Default - )in bold

Water Hardness Level

(see “SETTING THE WATER HARDNESS”

and “WATER HARDNESS TABLE”) 1 | 2 | | 4 | 53

Rinse Aid Level

(see “ADJUSTING THE DOSAGE OF RINSE AID”) 0 | 1 | 2 | 3 | 4 | 5

ActiveDry (see “OPTIONS AND FUNCTIONS”)

“1” = On, “0” = O 1 | 0

Light on the oor (see “OPTIONS AND FUNCTIONS”)

“1” = On, “0” = O 1 | 0

Sound

“1” = On, “0” = O 1 | 0

Factory Settings

Press START/Pause to restore to the factory

default all the values of the settings included

in the settings menu.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

The salt reservoir is located in the lower part of the dishwasher (under the

lower rack on the left side).

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

• Salt must be lled when the SALT REFILL indicator light on the control

panel is lit. 1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel and ll the salt reservoir (see gure)

right up to its edge (approximately 0,5 kg); it is not un-

usual for a little water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly so that no detergent can get into

the container during the wash program (this could damage the water

softener beyond repair).

Run a program every time as soon as you completed relling the salt

reservoir to avoid corrosion.

Setting the water hardness

To allow the water softener to work in a perfect way, it is essential that the

water hardness setting is based on the actual water hardness in your house.

This information can be obtained from your local water supplier. The facto-

ry setting is “3”. See „WATER HARDNESS TABLE” .

To change, follow instructions in section “SETTING MENU”.

Only use salt that has been specically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL indicator

light switches o.

If the salt container is not lled, the water softener and the heating

element may be damaged as a result of limescale accumulation.

Use of salt is recommended with any type of dishwasher detergent.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently preventing

scale buildup on the heater, contributing also to better cleaning eciency.

This system regenerates itself with salt, therefore it is required to rell

the salt container when empty. The frequency of regeneration depends

on the water hardness level setting - regeneration takes place once per 4-6

Eco cycles with the water hardness level set to . The regeneration process 3

occurs at the beginning of the cycle with additional fresh water.

• Single regeneration consumes: ~3L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dispenser should be A

lled when the RINSE AID REFILL indicator light in the control panel is lit.

1. Open the dispenser B by

pressing and pulling up the

tab on the lid.

2. Pour in the rinse aid (max.110

ml), making sure it does not

overow from the dispenser.

If this happens, clean the spill

immediately with a dry cloth.

3. Press the lid down until you hear a click to close it.

NEVER pour the rinse aid directly into the appliance tub.

Adjusting the dosage of rinse aid

If you are not completely satised with the drying results, you can adjust

the quantity of rinse aid used.

To change, follow instructions in the section “SETTING MENU”.

If the rinse aid level is set to ZERO, no rinse aid will be supplied. The LOW

RINSE AID indicator light will not be lit if you run out of rinse aid.

A maximum of levels can be set according to the dishwasher model. 6

• If you see bluish streaks on the dishes, set a low number (0-3).

• If there are drops of water or limescale marks on the dishes, set

a mid-range number (4-5).

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device C. Introduce

the detergent into the dry dispenser D only. Place the amount of

detergent for pre-washing directly inside the tub.

1. When measuring out the detergent refer to the

mentioned earlier information to add the proper

quantity. Inside the dispenser , there are indicaD-

tions to help the detergent dosing.

2. Remove detergent residues from the edges of the

dispenser and close the cover until it clicks.

3. Close the lid of the detergent dispenser by pulling

it up until the closing device is secured in place.

The detergent dispenser automatically opens up at

the right time according to the program.

Usage of detergent not designed for dishwashers may cause

malfunction or damage to the appliance.

CONTROL PANEL

1. ON-OFF/Reset button with indicator light

2. PREVIOUS program button

3. NEXT program button

4. FAVOURITE program button

with indicator light

5. Salt reservoir empty indicator light

6. Rinse Aid reservoir empty indicator light

7. DESCALE indicator light

8. Closed Water Tap indicator light

9. Display

10. Program number remaining time and indicator

11. Power Clean® option button with indicator light

12. Half Load option button with indicator light/ - 3 sec. pressSettings

13. Extra Dry option button with indicator light

14. Delay option button with indicator light

15. START/Pause button with indicator light

Water Hardness Table

Level °dH

German degrees

°fH

French degrees

°Clark

English degrees

1 (soft) 0 - 6 0 - 10 0 - 7

2 (medium) 7 - 11 11 - 20 8 - 14

3 (average) 12 - 16 21 - 29 15 - 20

4 (hard) 17 - 34 30 - 60 21 - 42

5 (very hard) 35 - 50 61 - 90 43 - 62

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

3 sec.

1. CHECK WATER CONNECTION

Check that the dishwasher is connected to the water supply and that

the tap is open.

2. SWITCH ON THE DISHWASHER

Open the door and press the button.ON/OFF

3. LOAD THE RACKS (see LOADING THE RACKS).

4. FILL THE DETERGENT DISPENSER

5. CHOOSE THE PROGRAM AND CUSTOMISE THE CYCLE

Select the most appropriate program in accordance with the type of

crockery and its soiling level (see PROGRAMS DESCRIPTION) by pressing

the buttons.PREVIOUS/NEXT

Select the desired options . Not all (see OPTIONS AND FUNCTIONS)

options are compatible with all programs.

6. START

Start the wash cycle by pressing START/Pause button (led is lit) and

closing the door within 4 sec. When the program starts you hear a single

beep. If the door was not closed within 4sec., the alarm sound will be

played. In this case, open the door, press START/Pause button and close

the door again within 4 sec.

7. END OF WASH CYCLE

The end of the wash cycle is indicated by sound and the display shows

END. Open the door and switch o the appliance by pressing the

ON/OFF button.

Wait for a few minutes before removing the crockery - to avoid burns.

Unload the racks, beginning with the lower one.

MODIFYING A RUNNING PROGRAM

If a wrong program was selected, it is possible to change it, provided that it

has only just begun. the machine: press and hold the button RESET ON/OFF

for more than 3. sec., and the machine will switch o. The dashboard

will show “0:01”. Close the door and wait until drain cycle ends (around

1 minute). Open the door and switch the machine back on using the

ON/OFFbutton and select the new wash cycle and any desired options.

Start the cycle by pressing the START/Pause button and closing the door

within 4 sec.

ADDING EXTRA CROCKERY

Without switching o the machine, open the door rst slightly to avoid water

splashing out (START/Pause led starts blinking) ( ) and Caution!: Hot steam!

place the crockery inside the dishwasher. Press the START/Pause button and

close the door within 4 sec., the cycle will resume from the point at which it

was interrupted.

ACCIDENTAL INTERRUPTIONS

If the door is opened during the wash cycle, or if there is a power cut, the

cycle stops. ONLY IF YOU PRESS the START/Pause button and close the

door within 4 sec., the cycle will resume from the point at which it was

interrupted.

TIPS

Before loading the baskets, remove all food residues from the crockery

and

empty the glasses. You do not need to rinse beforehand under running

water.

Arrange the crockery so that it is held in place rmly and does not tip over;

and arrange the containers with the openings facing downwards and the

concave/convex parts placed obliquely, thus allowing the water to reach

every surface and ow freely.

Warning: lids, handles, trays and frying pans should not prevent the spray-

er arms from rotating.

Place any small items in the cutlery basket.

Very soiled dishes and pans should be placed in the lower basket because

in this sector the water sprays are stronger and allow a higher washing per-

formance.

After loading the appliance, make sure that the sprayer arms can rotate

freely.

UNSUITABLE CROCKERY

• Wooden crockery and cutlery.

• Delicately decorated glasses, artistic handicrafts and antique crockery.

Their decorations are not resistant.

• Parts in synthetic material which do not withstand high temperatures.

• Copper and tin crockery.

• Crockery soiled with ash, wax, lubricating grease or ink.

The colours of glass decorations and aluminium/silver pieces can change

and fade during the washing process. Some types of glass (e.g. crystal ob-

jects) can become opaque after a number of wash cycles too.

DAMAGE TO GLASS AND CROCKERY

• Only use glasses and porcelain guaranteed by the manufacturer as dish-

washer safe.

• Use a delicate detergent suitable for crockery

• -Collect glasses and cutlery from the dishwasher as soon as the wash cy

cle is over.

TIPS ON ENERGY SAVING

• When the household dishwasher is used according to the manufacturer’s

instructions, washing tableware in a dishwasher usually consumes

less energy and water than hand dishwashing.

• In order to maximize dishwasher eciency, it is recommended to in-

itiate the wash cycle once the dishwasher is fully loaded. Loading

the household dishwasher up to the capacity indicated by the manu-

facturer will contribute to energy and water savings. Information on

the correct loading of tableware can be found in the Loading chapter.

In case of partial loading, it is recommended to use a dedicated wash op-

tions if available (Half load/ Zone Wash/ Multizone), lling up only select-

ed racks. Incorrect loading or overloading of the dishwasher may increase

resources usage (such as water, energy and time, as well as increase noise

level), reducing cleaning and drying performance.

• Manual pre-rinsing of tableware items leads to increased water and ener-

gy consumption and is not recommended.

HYGIENE

To avoid odour and sediment which can be accumulated in the dishwasher

please run a high-temperature program at least once a month. Use a tea-

spoon of detergent and run it without loading to clean your appliance.

RESISTANCE TO FROST

If the appliance is placed in surroundings exposed to the risk of frost, it

must be drained completely. Turn o the water tap, remove the inlet and

outlet hoses, and let all the water drain away. Make sure that the water

softener is full of dissolved regeneration salt in the salt container, to

protect the appliance from temperatures of up to -20°C.

If the appliance was stored in frost conditions the appliance must remain at

an ambient temperature of min. 5°C for before the rst run.at least 24 hours

ADVICE AND TIPS

DAILY USE

ENDaily Reference Guide

PROGRAMS TABLE

Program Programs description

Drying

phase

ActiveDry

Available options *)

Duration

of wash

program

(h:min)**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco - Program is suitable to clean normally soiled tablewa-50°

re, that for this use, it is the most ecient program in terms of

its combined energy and water consumption, and that it is used

to assess compliance with the EU Ecodesign legislation. 3:30 9.5 0.75

P2 Auto Intensive - 65° Automatic pro-

gram for heavily soiled dishes and pans. Senses the level of so-

iling on the dishes and

adjusts the program

accordingly. When the

sensor is detecting the

soil level an animation

appears in the display

and the cycle duration

is updated.

2:25-3:10 15.5-24.5 1.30-1.70

Auto Mixed - 55° Automatic program

for normally soiled dishes with dried

food residues. 1:20-3:00 7.5-19.5 0.75-1.20

Auto

Fast

50° - Automatic program for

normally and lightly soiled dishes. The

everyday cycle that ensures optimal

cleaning and drying performance in a

shorter time.

1:00-1:50 7.5-15.5 0.70-1.10

Rapid 45°

- Program is recommended for limited amount of li-

ghtly-soiled dishes with no dried food residues. Does not include

the drying phase.

- 0:30-0:40 10-12 0.55-0.65

Crystals - 45° Program for delicate items, which are more sensiti-

ve to high temperatures, for example, glasses and cups.

1:40-1:50 12.5-16.5 0.95-1.20

Silent - 55° Suitable for night-time operation of the appliance.

Ensures optimal cleaning and drying performance with the

lowest noise emission. 3:50-4:10 10.5-14.5 0.80-1.15

Sanitizing - 65° Normally or heavily soiled crockery, with

additional antibacterial wash. Can be used to perform mainte-

nance of the dishwasher. - 1:55-2:10 12-19 1.40-1.80

P9 Prewash - Used to refresh crockery planned to be washed

later. No detergent is to be used with this program. - 0:12 4.5 0.10

P10

Self Clean - 65° Program to be used to perform maintenance

of the dishwasher, to be carried out only when the dishwasher

is EMPTY using specic detergents designed for dishwasher

maintenance.

-- 1:15 11.0 1.10

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address: dw_test_support@whirlpool.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and pressure of the incoming

water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor calibration. The sensor calibration can increase

program duration by up to 20 min.

OPTIONS can be selected/ deselected, after choosing the program, directly by pressing the corresponding button (if available - the indicator lights up)

(see CONTROL PANEL) (see PROGRAMS TABLE). If an option is not compatible with the selected program , the corresponding LED ashes rapidly

3 times and beeps will sound. The option will not be enabled. An option can change time or water or energy consumption for the program.

OPTIONS AND FUNCTIONS

HALF LOAD - If there are not many dishes to be washed, HALF LOAD

is used to save water, electricity or time, depending on the selected

program. Remember to reduce the amount of detergent.

EXTRA DRY - The higher temperature during the final rinse and the

extended drying phase which allows for improved drying. The EXTRA

DRY option results in the lengthening of the wash cycle.

DELAY - The start of the program may be delayed for a period of time

between and hours.0:30 24

1. Select the program and any desired options. Press the DELAY button

(repeatedly) to delay the start of the program. Adjustable from 0:30 to 24

hours. Once the 24 hours setting is reached, press the DELAY another time

to deactivate the DELAY function.

2. Press the START/Pause button and close the door within 4 sec. the timer

will begin counting down.

3. Once this time has elapsed, the indicator light switches o and the program

begins automatically.

The DELAY function cannot be set once a program has been started.

POWER CLEAN® - Thanks to the additional power jets this option

provides a more intensive and powerful wash in the lower rack, in the

specific area. This option is recommended for washing pots and casseroles

(please refer to the Power Clean in loading section). ®

FAVOURITE PROGRAM  The FAVOURITE program may be saved and

will be easily accessible. Find the program using PREVIOUS/NEXT, and

then press the FAVOURITE program button for 3 seconds.

WATER TAP CLOSED – Alarm - Flashes when there is no inlet water or

water tap is closed.

LIGHT ON THE FLOOR - A LED light projected on the oor indicates

that the dishwasher is working. The light goes o at the end of a cycle.

This feature is active by default, but it is possible to deactivate it in the

“SETTINGS MENU”.

ActiveDry - It is a convection drying system which automatically opens

the door during/after the drying phase to ensure exceptional drying

performance every day. The door opens at a temperature that is safe to

your kitchen furniture.

As additional steam protection, specially designed protection foil is added

together with the dishwasher.

To see how to mount protection foil please refer to INSTALLATION GUIDE.

This feature is active by default, but it is possible to deactivate it in the

“SETTINGS MENU”.

DESCALE – Alarm - Limescale accumulation was detected on the

internal components of the appliance. Check if the Water Hardness

Setting salt is at the correct value and is present in the salt container (see

FIRST TIME USE), then (WPro brand is recommended) use a descaling product

with the . After a successful descaling, the icon will stop Self-Clean program

being displayed.

If the actions above are not performed, product performance will deteriorate.

DESCALE warning will start blinking and « » alarm will appear on the dES

display. If still no action is taken, the appliance will only allow a certain

number of cycles to be started (indicated during « » alarm display) dES

and then will be BLOCKED to prevent component damage, with only

the Self-Clean program available. Performing a full descaling will unblock

the product. In the case of extremely high amounts of limescale, descaling

may have to be performed twice to be ecient.

SENSING - When the sensor is detecting the soil level an

animation appears in the display (around 20 min.) and the cycle

duration is updated. is for the level of soiling on the dishes and it SENSING

is present for all cycles (excepting Eco) adjusting the program accordingly.

Produktspezifikationen

Marke:	Bauknecht
Kategorie:	Spülmaschine
Modell:	B8I HP42 LC

Brauchst du Hilfe?

Wenn Sie Hilfe mit Bauknecht B8I HP42 LC benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Spülmaschine Bauknecht

Bauknecht GSXK 5011 A+ Bedienungsanleitung

16 Oktober 2024

Bauknecht BCIC 3T333 PFE CH Bedienungsanleitung

5 Oktober 2024

Bauknecht GSFK 61312 TR WS Bedienungsanleitung

30 September 2024

Bauknecht B0I D551A S Bedienungsanleitung

24 September 2024

Bauknecht GSF 4040 Bedienungsanleitung

23 September 2024

Bauknecht BKBC 3C26 X Bedienungsanleitung

18 September 2024

Bauknecht GSXP 7598 2 Bedienungsanleitung

14 September 2024

Bauknecht BCIC 3C26 E CH Bedienungsanleitung

11 September 2024

Bauknecht GSIH 6451 IN Bedienungsanleitung

9 September 2024

Bauknecht B0U D651A X Bedienungsanleitung

6 September 2024

Bedienungsanleitung Spülmaschine

Neueste Bedienungsanleitung für -Kategorien-

Freggia DWI4108 Bedienungsanleitung

16 Oktober 2024

Neff S155EVX04E Bedienungsanleitung

16 Oktober 2024

Neff S255EVX04E Bedienungsanleitung

16 Oktober 2024

Neff S145EVS04E Bedienungsanleitung

16 Oktober 2024

V-ZUG GS60Ni3n Bedienungsanleitung

15 Oktober 2024

Grundig GNUP4530W Bedienungsanleitung

15 Oktober 2024

Grundig GNLP4620X Bedienungsanleitung

15 Oktober 2024

Grundig GNUP3540W Bedienungsanleitung

15 Oktober 2024

Royal Catering RCDW-06 Bedienungsanleitung

15 Oktober 2024

Royal Catering RCDW-05 Bedienungsanleitung

15 Oktober 2024
