ENDaily Reference Guide

THANK YOU FOR BUYING A BAUKNECHT PRODUCT.

In order to receive a more complete assistance, please

4 5 6 7 8 9 10 13 14 1511 12 16 17 18 191 2 3 20 21 22

1. ON-OFF/Reset button with indicator light

2. Eco program button with indicator light

3. Auto Intensive program button with indicator light

4. Auto Mixed program button with indicator light

5. Auto Fast program button with indicator light

6. Rapid program button with indicator light

7. Glass

program button with indicator light/ - 3 sec. pressSelf-Clean program

8. Prewash program button with indicator light

9. Salt reservoir empty indicator light

10. Rinse Aid reservoir empty indicator light

11. Display

12. Program number remaining time and indicator

13. Closed water tap indicator light

14. DESCALE indicator light

15. Power Clean® option button with indicator light

16. Half Load option button with indicator light

17. Extra Dry option Settings button with indicator light/ - 3 sec. press

18. Silent option button with indicator light

19. Sani Rinse option button with indicator light

20. Turbo option button with indicator light

21. Delay option button with indicator light

22. START/Pause button with indicator light

SETTING MENU

1. Switch on the appliance by pressing the button.ON-OFF

2. Hold the Settings (Extra Dry ) button for 3 seconds, until you hear

a beep and the display shows „ ”.SEt

3. After one second the rst available setting (letter „ ”) will be displayed.h

4. Press Prewash program / Power Clean® option buttons to scroll

through the list of available settings (see table below), then press START/

Pause to view and change the value of currently selected setting.

5. Press Prewash program Power Clean® option /

buttons

change the value, then press START/Pause to save the new value.

6. To change another setting, repeat points 2 and 5.

7. Press or wait 30 seconds to exit the menu.ON-OFF

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

The salt reservoir is located in the lower part of the dishwasher (under the

lower rack on the left side).

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

• Salt must be lled when the SALT REFILL indicator light on the con-

trol panel is lit.1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel and ll the salt reservoir (see gure)

right up to its edge (approximately 0,5 kg); it is not un-

usual for a little water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly so that no detergent can get into

the container during the wash program (this could damage the water

softener beyond repair).

Run a program every time as soon as you completed relling the salt

reservoir to avoid corrosion.

LETTER SETTING VALUES

(Default - )in bold

Water Hardness Level

(see “SETTING THE WATER HARDNESS”

and “WATER HARDNESS TABLE”) 1 | 2 | | 4 | 53

Rinse Aid Level

(see “ADJUSTING THE DOSAGE OF RINSE AID”)

0 | 1 | 2 | 3 |

4 | 5

ActiveDry (see “OPTIONS AND FUNCTIONS”)

“1” = On, “0” = O 1 | 0

Time on the oor (see “OPTIONS AND FUNCTIONS”)

“1” = On, “0” = O 1 | 0

Sound

“1” = On, “0” = O 1 | 0

Internal Lights (see “OPTIONS AND FUNCTIONS”)

“1” = On, “0” = O

1 | 0

Factory Settings

Press START/Pause to restore to the factory

default all the values of the settings included in

the settings menu.

Setting the water hardness

To allow the water softener to work in a perfect way, it is essential that the water

hardness setting is based on the actual water hardness in your house. This infor-

mation can be obtained from your local water supplier. The factory setting is “3”.

See „WATER HARDNESS TABLE”.

To change, follow instructions in section “SETTING MENU”.

Only use salt that has been specically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL indicator

light switches o.

If the salt container is not lled, the water softener and the heating

element may be damaged as a result of limescale accumulation.

Using of Salt is recommended with any type of dishwasher detergent.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently preventing

scale buildup on the heater, contributing also to better cleaning eciency.

This system regenerates itself with salt, therefore it is required to rell

the salt container when empty. The frequency of regeneration depends

on the water hardness level setting - regeneration takes place once per 4-6

Eco cycles with the water hardness level set to . During runs with regenera3-

tion, additional water management system ll will happen. The regeneration

and water management process occurs at the beginning of the cycle with

additional fresh water.

• Single regeneration consumes ~6,5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dispenser should be lled A

when the RINSE AID REFILL indicator light in the control panel is lit.

1. Open the dispenser B by

pressing and pulling up the

tab on the lid.

2. Pour in the rinse aid (max.

110 ml), making sure it does

not overow from the dis-

penser. If this happens, clean

the spill immediately with a

dry cloth.

3. Press the lid down until you hear a click to close it.

NEVER pour the rinse aid directly into the appliance tub.

Water Hardness Table

Level °dH

German degrees

°fH

French degrees

°Clark

English degrees

1 (Soft) 0 - 6 0 - 10 0 - 7

2 (Medium) 7 - 11 11 - 20 8 - 14

3 (Average) 12 - 16 21 - 29 15 - 20

4 (Hard) 17 - 34 30 - 60 21 - 42

5 (Very hard) 35 - 50 61 - 90 43 - 62

Before using the appliance carefully read

Safety and Installation Instructions. More information about your

product available on website: docs.bauknecht.eu

After installation, please remember to remove all transport protection

parts from the dishwasher.

CONTROL PANEL

FIRST TIME USE

DISPLAY ON THE FLOOR

1. Delay Time on the oor - indicator of the time left to the start of the cycle, when the Delay option is set

2. Salt reservoir empty - indicator light on the oor

3. Remaining Time on the oor - indicator of the time left to the end of the cycle

Adjusting the dosage of rinse aid

If you are not completely satised with the drying results, you can adjust

the quantity of rinse aid used.

To change, follow the instructions in the section “SETTING MENU”.

If the rinse aid level is set to ZERO, no rinse aid will be supplied. The LOW

RINSE AID indicator light will not be lit if you run out of rinse aid.

A maximum of levels can be set according to the dishwasher model. 6

• If you see bluish streaks on the dishes, set a low number (0-3).

• If there are drops of water or limescale marks on the dishes, set

a mid-range number (4-5).

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device C. Introduce

the detergent into the dry dispenser D only. Place the amount of

detergent for pre-washing directly inside the tub.

1. When measuring out the detergent refer to the

mentioned earlier information to add the proper

quantity. Inside the dispenser , there are indicaD-

tions to help the detergent dosing.

2. Remove detergent residues from the edges of the

dispenser and close the cover until it clicks.

3. Close the lid of the detergent dispenser by pulling

it up until the closing device is secured in place.

The detergent dispenser automatically opens up at the right time accord-

ing to the program.

Usage of detergent not designed for dishwashers may cause

malfunction or damage to the appliance.

1. CHECK WATER CONNECTION

Check that the dishwasher is connected to the water supply and that

the tap is open.

2. SWITCH ON THE DISHWASHER

Open the door and press the button.ON/OFF

3. LOAD THE RACKS (see LOADING THE RACKS).

4. FILL THE DETERGENT DISPENSER

5. CHOOSE THE PROGRAM AND CUSTOMISE THE CYCLE

Select the most appropriate program in accordance with the type of

crockery and its soiling level (see PROGRAMS DESCRIPTION) by pressing

the selected button.PROGRAM

Select the desired options . Not all (see OPTIONS AND FUNCTIONS)

options are compatible with all programs.

6. START

Start the wash cycle by pressing START/Pause button (led is lit) and

closing the door within 4 sec. When the program starts you hear a sin-

gle beep. If the door was not closed within 4sec., the alarm sound will

be played. In this case, open the door, press START/Pause button and

close the door again within 4 sec.

7. END OF WASH CYCLE

The end of the wash cycle is indicated by sound and the display shows

END. Open the door and switch o the appliance by pressing the ON/OFF

button.

Wait for a few minutes before removing the crockery - to avoid burns.

Unload the racks, beginning with the lower one.

MODIFYING A RUNNING PROGRAM

If a wrong program was selected, it is possible to change it, provided that it

has only just begun. the machine: press and hold the button RESET ON/OFF

for more than 3. sec., and the machine will switch o. The dashboard

will show “0:01”. Close the door and wait until drain cycle ends (around

1 minute). Open the door and switch the machine back on using the

ON/OFF button and select the new wash cycle and any desired options.

Start the cycle by pressing the START/Pause button and closing the door

within 4 sec.

ADDING EXTRA CROCKERY

Without switching o the machine, open the door rst slightly to avoid water

splashing out (START/Pause led starts blinking) (Caution! Hot steam!) and

place the crockery inside the dishwasher. Press the START/Pause button and

close the door within 4 sec., the cycle will resume from the point at which it

was interrupted.

ACCIDENTAL INTERRUPTIONS

If the door is opened during the wash cycle, or if there is a power cut, the

cycle stops. ONLY IF YOU PRESS the START/Pause button and close the

door within 4 sec., the cycle will resume from the point at which it was

interrupted.

WATER MANAGEMENT SYSTEM

This dishwasher allows the storage of up to 3.2 litres of fresh water

using it in the selected programs. Water is stored in a dedicated

tank and will be used in the subsequently selected programs. For

hygienic reasons, IT IS STRONGLY RECOMMENDED to perform a

cleaning cycle of the dishwasher periodically. It is recommended

to perform the Self-Clean cycle (see PROGRAMS TABLE) . periodically

DAILY USE

ADVICE AND TIPS

TIPS

Before loading the baskets, remove all food residues from the crockery

and

empty the glasses. You do not need to rinse beforehand under running

water.

Arrange the crockery so that it is held in place rmly and does not tip over;

and arrange the containers with the openings facing downwards and the

concave/convex parts placed obliquely, thus allowing the water to reach

every surface and ow freely.

Warning: lids, handles, trays and frying pans should not prevent the spray-

er arms from rotating.

Place any small items in the cutlery basket.

Very soiled dishes and pans should be placed in the lower basket because

in this sector the water sprays are stronger and allow a higher washing per-

formance.

After loading the appliance, make sure that the sprayer arms can rotate

freely.

UNSUITABLE CROCKERY

• Wooden crockery and cutlery.

• Delicately decorated glasses, artistic handicrafts and antique crockery.

Their decorations are not resistant.

• Parts in synthetic material which do not withstand high temperatures.

• Copper and tin crockery.

• Crockery soiled with ash, wax, lubricating grease or ink.

The colours of glass decorations and aluminium/silver pieces can change

and fade during the washing process. Some types of glass (e.g. crystal ob-

jects) can become opaque after a number of wash cycles too.

DAMAGE TO GLASS AND CROCKERY

• Only use glasses and porcelain guaranteed by the manufacturer as dish-

washer safe.

• Use a delicate detergent suitable for crockery

• -Collect glasses and cutlery from the dishwasher as soon as the wash cy

cle is over.

TIPS ON ENERGY SAVING

• When the household dishwasher is used according to the manufacturer’s

instructions, washing tableware in a dishwasher usually consumes

less energy and water than hand dishwashing.

• In order to maximize dishwasher eciency, it is recommended to in-

itiate the wash cycle once the dishwasher is fully loaded. Loading

the household dishwasher up to the capacity indicated by the manu-

facturer will contribute to energy and water savings. Information on

the correct loading of tableware can be found in the Loading chapter.

In case of partial loading, it is recommended to use a dedicated wash op-

tions if available (Half load/ Zone Wash/ Multizone), lling up only select-

ed racks. Incorrect loading or overloading of the dishwasher may increase

resources usage (such as water, energy and time, as well as increase noise

level), reducing cleaning and drying performance.

• Manual pre-rinsing of tableware items leads to increased water and ener-

gy consumption and is not recommended.

HYGIENE

To avoid odour and sediment which can be accumulated in the dishwasher

please run a high-temperature program at least once a month. Use a tea-

spoon of detergent and run it without loading to clean your appliance.

MOVING OR SERVICING THE DISHWASHER

This dishwasher includes a water tank that may remain full of water after

the cycle ends (water can leak out if / when the dishwasher is tipped). Note:

Before servicing or moving the dishwasher, run the Self-Clean cycle to drain

the water tank.

RESISTANCE TO FROST

If the appliance is placed in surroundings exposed to the risk of frost, it

must be drained completely. completely. Run the Self-Clean cycle to

drain the water tank. Turn o the water tap, remove the inlet and out-

let hoses, and let all the water drain away. Make sure that the water

softener is full of dissolved regeneration salt in the salt container, to

protect the appliance from temperatures of up to -20°C.

If the appliance was stored in frost conditions the appliance must remain at

an ambient temperature of min. 5°C for before the rst run.at least 24 hours

ENDaily Reference Guide

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address: dw_test_support@whirlpool.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration by up to 20 min.

Program

Programs description

Drying

phase

Active-

Dry

Available

options *)

Duration

of wash

program

(h: min)**)

Water

con-

sumption

(litres/cycle)

Energy

con-

sumption

(kWh/cycle)

Eco 50°- program is suitable to clean normally soiled table-

ware, that for this use, it is the most ecient program in

terms of its combined energy and water consumption, and

that it is used to assess compliance with the EU Ecodesign

legislation.

4:30 9.5 0.55

Auto Intensive - 65° Automatic

program for heavily soiled dishes and

pans.

Senses the level of

soiling on the dishes

and adjusts the

program according-

ly. When the sensor

is detecting the soil

level an animation

appears in the

display and the cycle

duration is updated.

2:25 - 3:10 15.5 - 24.5 1.30 - 1.70

Auto Mixed - 55° Automatic program

for normally soiled dishes with dried

food residues. 1:20 - 3:00 7.5 - 19.5 0.75 - 1.20

Auto Fast 50° - Automatic program for

normally and lightly soiled dishes. The

everyday cycle that ensures optimal

cleaning and drying performance in

shorter time.

1:00 - 1:50 0.70 - 1.107.5 - 15.5

Rapid - 45°

Program is recommended for limited amount of

lightly-soiled dishes with no dried food residues. Does not

include the drying phase.

- 0:30 - 0:40 0.55 - 0.6510.0 - 12.0

Glass - 45° Program for delicate items, which are more sensitive

to high temperatures, for example glasses and cups.

1:40 - 1:50 12.5 - 16.5 0.95 - 1.20

Prewash - Use to refresh crockery planned to be washed

later. No detergent is to be used with this program. - 0:12 4.5 0.10

Self-Clean - 65° Program to be used to perform mainte-

nance of the dishwasher and water management system,

to be carried out only when the dishwasher is EMPTY using

specic detergents designed for dishwasher maintenance.

-- 1:40 11.0 1.10

TIME ON THE FLOOR - A LED light projected on the oor indicates the

time left to the end of the cycle. The light goes o every time the door

is opened. The light goes o at the end of a cycle.This feature is active

by default, but it is possible to deactivate it in the “SETTINGS MENU”.

POWER CLEAN® - Thanks to the additional power jets this option

provides a more intensive and powerful wash in the lower rack, in the

specific area. This option is recommended for washing pots and casseroles

(Please refer to the Power Clean® loading section).

EXTRA DRY - The higher temperature during the final rinse and the

extended drying phase allow improved drying.

DELAY - The start of the program may be delayed for a period of time

between and hours.0:30 24

1. Select the program and any desired options. Press the DELAY button

(repeatedly) to delay the start of the program. Adjustable from 0:30 to 24

hours. Once the 24 hours setting is reached, press the DELAY another time

to deactivate the DELAY function.

2. Press the START/Pause button and close the door within 4 sec. the timer

will begin counting down.

3. Once this time has elapsed, the indicator light switches o and the program

begins automatically.

The DELAY function cannot be set once a program has been started.

WATER TAP CLOSED – Alarm - Flashes when there is no inlet water or

water tap is closed.

ActiveDry - I

t is a convection drying system which automatically opens the

door during/after drying phase to ensure exceptional drying performance

every day. Door opens at the temperature that is safe to your kitchen furni-

ture, thus door will not be opened when the option of SANI RINSE is on.

additional steam protection, special designed protection foil is added to-

gether with the dishwasher.

To see how to mount protection foil please refer to the INSTALLATION GUIDE.

This feature is active by default, but it is possible to deactivate it in

the “SETTINGS MENU”.

INTERNAL LIGHTS  When the feature is active the LEDs in the tub are

automatically switched on/o as soon as the user open/close the door

respectively.

If the door remains opened for more than 10 min, the LEDs in the

tub switch o (to turn them on again, the door has to be closed and opened

again).

This feature is active by default, but it is possible to deactivate it in

the “SETTINGS MENU”.

SILENT - Suitable for night-time operation of the appliance. This option

can be used to limit noise emission during wash phases. It will increase

cycle time depending on base cycle selection.

SANI RINSE - This option can be used to sanitize washed dishes. It will

increase the nal rinse temperature and add antibacterial wash to the

selected program. Ideal to clean crockery and feeding bottles. The dishwasher

door must be kept shut for the entire duration of the program in order to

guarantee reduction of germs.

WARNING: the crockery and plates could be extremely hot at the end

of the cycle.

TURBO - Thanks to the Turbo option you can reduce time up to 40%

depending on the selected based program. Energy and water

consumption are increased.

PROGRAMS TABLE

OPTIONS AND FUNCTIONS

SENSING - When the sensor is detecting the soil level an

animation appears in the display (around 20 min.) and the cycle

duration is updated. is for the level of soiling on the dishes and is SENSING

present for all cycles (excepting Eco) adjusting the program accordingly.

HALF LOAD - If there are not many dishes to be washed, HALF LOAD is

used to save water, electricity or time, depending on the selected program.

Remember to halve the amount of detergent.

OPTIONS can be selected/ deselected, after choosing the program, directly by pressing the corresponding button (if available - the indicator lights up) (see

CONTROL PANEL) (see PROGRAMS TABLE). If an option is not compatible with the selected program , the corresponding LED ashes rapidly 3 times and beeps will
