Seite 1/197

Installation,

Conﬁguration

and Operation

FRITZ!Box

Fon WLAN 7270

Legal Notice

FRITZ!Box Fon WLAN 7270 2

Legal Notice

FRITZ!Box Fon WLAN 7270

This documentation and the software it describes are protected by copyright. AVM grants the non-

exclusive right to use the software, which is supplied exclusively in what is known as object code

format. The licensee may create only one copy of the software, which may be used exclusively for

backup use.

AVM reserves all rights that are not expressly granted to the licensee. Without previous approval

in writing, and except for in cases permitted by law, it is particularly prohibited to

•copy, propagate or in any other manner make this documentation or this software publicly ac-

cessible, or

•process, disassemble, reverse engineer, translate, decompile or in any other manner open

the software and subsequently copy, propagate or make the software publicly accessible in

any other manner.

Please consult the “License.txt” file on the product CD included in the package for specifics about

the licensing conditions.

This documentation and software have been produced with all due care and checked for correct-

ness in accordance with the best available technology. AVM GmbH disclaims all liability and war-

ranties, whether express or implied, relating to the AVM product’s quality, performance or suit-

ability for any given purpose which deviates from the performance specifications contained in the

product description. The licensee bears all risk in regard to hazards and impairments of quality

which may arise in connection with the use of this product.

AVM will not be liable for damages arising directly or indirectly from the use of the manual or the

software, nor for incidental or consequential damages, except in case of intent or gross negli-

gence. AVM expressly disclaims all liability for the loss of or damage to hardware or software or

data as a result of direct or indirect errors or destruction and for any costs (including connection

charges) related to the documentation and the software and due to incorrect installations not per-

formed by AVM itself.

The information in this manual and the software are subject to change without notice for the pur-

pose of technical improvement.

We offer a manufacturer’s warranty for this original product. The conditions of this warranty are

contained in the “Warranty.pdf” file in the “Info” folder on the product CD included with delivery.

AVM in the Internet: www.avm.de/en

Unless otherwise indicated, all trademarks mentioned are legally protected trademarks owned by

AVM. This includes product names and logos in particular. Microsoft, Windows and the Windows

logo are trademarks owned by Microsoft Corporation in the USA and/or other countries. Bluetooth

is a trademark of Bluetooth SIG, Inc. licensed to AVM GmbH. All other product and company

names are trademarks of their respective owners.

AVM Audiovisuelles Marketing

und Computersysteme GmbH

Alt-Moabit 95

D 10559 Berlin

AVM Computersysteme

Vertriebs GmbH

Alt-Moabit 95

D 10559 Berlin

F!BoxFonWLAN-7270-e.book Seite 2 Donnerstag, 7. April 2011 5:36 17

FRITZ!Box Fon WLAN 7270 3

Table of Contents

Symbols and Highlighting . . . . . . . . . . . . . . . . . . . . . . . . . 8

I CONNECTING AND OPERATION . . . . . . . . . . . . . . . . . . . . . . 9

1 Security and Handling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2 FRITZ!Box Fon WLAN 7270 . . . . . . . . . . . . . . . . . . . . . . . . 11

2.1 Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.2 Operation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3 Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.1 Launching Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.2 Connecting to Electrical Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.3 Connecting to the Computer(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.4 Connecting Computers to the LAN Port . . . . . . . . . . . . . . . . . . . . . . . . 18

3.5 Connecting Computer(s) Wirelessly via WLAN . . . . . . . . . . . . . . . . . . 20

3.6 Connecting to the DSL Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

3.7 Connecting to the ISDN Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

3.8 Connecting with the Analog Telephone Line. . . . . . . . . . . . . . . . . . . . 27

3.9 Connecting Telephone, Fax, or Answering Machine . . . . . . . . . . . . . . 28

3.10 Connecting ISDN Telephones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

3.11 Connecting ISDN PBXs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

3.12 Connecting IP Telephones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

4 Opening the User Interface. . . . . . . . . . . . . . . . . . . . . . . . 32

4.1 Password Protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

4.2 Saving Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

5 Internet Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

5.1 Configuring the Internet Connection via DSL Using the Wizard . . . . . 35

5.2 Configuring the Internet Connection Manually . . . . . . . . . . . . . . . . . . 35

5.3 Internet Connection via the Mobile Telephone Network . . . . . . . . . . 36

5.4 Surfing the Net . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

F!BoxFonWLAN-7270-e.book Seite 3 Donnerstag, 7. April 2011 5:36 17

Produktspezifikationen

Marke:	AVM
Kategorie:	Router
Modell:	Fritz!Box 7270
WLAN-Standards:	802.11a, 802.11b, 802.11g
Breite:	210 mm
Tiefe:	155 mm
Gewicht:	- g
AC-Netzadapter:	Ja
Mitgelieferte Kabel:	LAN (RJ-45), Phone (RJ-11)
Produktfarbe:	Red, White
Höhe:	25 mm
AC Eingangsspannung:	230 V
AC Eingangsfrequenz:	50 Hz
Gleichstrom-Anschluss (DC):	Ja
Betriebstemperatur:	0 - 40 °C
Relative Luftfeuchtigkeit in Betrieb:	10 - 90 %
Netzstandard:	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Unterstützte Sicherheitsalgorithmen:	TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK
Unterstützte Netzwerkprotokolle:	IPv6, SMB, FTP, UPnP AV
Eingebauter Ethernet-Anschluss:	Ja
Schnittstellentyp Ethernet-LAN:	Schnelles Ethernet
Stromverbrauch (Standardbetrieb):	8 W
Power over Ethernet (PoE):	Nein
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	4
Betriebsanleitung:	Ja
Ethernet LAN Datentransferraten:	10, 100 Mbit/s
Anzahl der Antennen:	3
LED-Anzeigen:	Power, WLAN
Temperaturbereich bei Lagerung:	-20 - 70 °C
Luftfeuchtigkeit bei Lagerung:	5 - 95 %
Unterstützt Windows-Betriebssysteme:	Ja
Rack-Einbau:	Nein
Unterstützt Mac-Betriebssysteme:	Ja
Anzahl der USB-Anschlüsse:	1
Web-basiertes Management:	Ja
Top WLAN-Standard:	Wi-Fi 4 (802.11n)
DSL-WAN:	Ja
WLAN-Band:	Nein
WLAN Datentransferrate (max.):	300 Mbit/s
Verkabelungstechnologie:	10/100Base-T(X)
Firewall:	Ja
VoIP Protokolle:	SIP
DHCP-Client:	Ja
DHCP-Server:	Ja
Unterstützte Linux-Betriebssysteme:	Ja
Datenübertragungsgeschwindigkeit WLAN:	11, 54, 300 Mbit/s
xDSL-Verbindung:	Ja
RJ-11 ports Quantität:	4
Bandbreite (erste):	2.4 GHz
Bandbreite (zweite):	5 GHz
ADSL Spezifikation:	ADSL, ADSL2+
ISDN Anschluss:	Ja
ADSL2+:	Ja
Abwärts gerichtete Datenrate:	16 Mbit/s
