INSTALLATION MANUAL
WMM630 WOODEN IN-CEILING/WALL SPEAKER BACK BOX
STEP 1 STEP 2
Install the included L-shaped mounting brackets onto
the back-box. Depending on the installation direction
(horizontal or vertical) and the width between the
supporting beams, the L-shaped brackets can be
mounted in two dierent directions. The mounting
holes for the L-brackets are partially pre-drilled. Use
the included fasteners for assembling the L-brackets.
Install the back box on the provided wall or ceiling
location in between the supporting beams. Make sure
the structure can support the weight of the back box
and the speaker to be installed into it. Depending on
the structural material the appropriate fasteners shall
be used.
STEP 3
Adjust the cut-out for the installed speaker according
to the required diameter (if necessary). Various
cut-outs for dierent diameters are marked on the
back-box for easy cutting. Provide the connection
cable into the back-box by drilling a hole and pulling
the cable through it. Make sure the hole is properly
sealed afterwards.
STEP 4
Finish the structure by placing finishing board
(plasterboard, wood, ... ) in front of it. Afterwards,
connect, insert and install the speaker into the
provided location.
The WEEE marking indicates that this product
should not be disposed with regular household
waste at the end of its product life. This regulation
is created to protect both the environment and
human health.
This product is developed and manufactured with
high quality materials and components which can
be recycled and/or reused. Please dispose of this
product at your local collection point or recycling
center for electrical and electronic waste. Do this
to make sure that the product is recycled in an
environmental friendly way, and help to protect
the environment in which we all live.
INSTALLATION MANUAL
WMM630 WOODEN IN-CEILING/WALL SPEAKER BACK BOX
•
IF THERE IS ANY DAMAGE TO THE CARTON BOX
OR THE UNIT ITSELF, INFORM YOUR VENDOR
IMMEDIATELY.
•
ALWAYS FOLLOW THE LOCAL REGULATIONS AND
REQUIREMENTS REGARDING INSTALLATION,
SUSPENSION AND CONNECTION OF THIS
LOUDSPEAKER. EVEN WHEN OTHERWISE SPECIFIED
IN THIS DOCUMENT.
• THE INSTALLATION OF THIS LOUDSPEAKER SHALL
BE DONE BY QUALIFIED PERSONNEL ONLY.
•
ALWAYS KEEP THESE INSTRUCTIONS FOR FUTURE
REFERENCE. NEVER THROW THEM AWAY
• ALWAYS HANDLE THIS UNIT WITH CARE
• CLEAN ONLY WITH DRY CLOTH
•
HEED ALL WARNINGS AND FOLLOW ALL
INSTRUCTIONS
•
NEVER EXPOSE THIS EQUIPMENT TO RAIN,
MOISTURE, ANY DRIPPING OR SPLASHING LIQUID.
•
DO NOT INSTALL THIS UNIT NEAR ANY HEAT
SOURCES SUCH AS RADIATOR S OR OTHER
APPARATUS THAT PRODUCE HEAT
•
DO NOT PLACE THIS UNIT IN ENVIRONMENTS
WITH A HIGH LEVEL OF DUST, HEAT, MOISTURE OR
VIBRATION
• THIS UNIT IS DEVELOPED FOR INDOOR USE ONLY.
DO NOT USE IT OUTDOORS
•
ONLY USE ATTACHMENTS & ACCESSORIES SPECIFIED
BY THE MANUFACTURER.
•
ONLY INSTALL THE SPEAKER IN LOCATIONS THAT
CAN STRUCTURALLY SUPPORT THE WEIGHT OF THE
SPEAKER. IGNORING THIS CAN BRING THE SPEAKER
DOWN.
•
DO NOT USE ANY OTHER METHOD THAN SPECIFIED
TO MOUNT THE SPEAKER. IF EXTREME FORCE IS
APPLIED TO THE SPEAKER, IT COULD FALL DOWN
•
ATTACH A SAFETY WIRE TO THE SPEAKER WHEN
IT IS MOUNTED HIGH UP. ONLY USE INDUSTRY-
ACCEPTED RIGGING TOOLS AND METHODS
• CAREFULLY CHECK THE UNIT’S CONDITION AFTER
UNPACKING.
PRECAUTIONS
This product contains no user serviceable parts.
Refer all servicing to qualied service personnel. Do
not perform any servicing (unless you are qualied
to do so.)
CAUTION - SERVICING
This product conforms to all the essential
requirements and further relevant specications
described in following directives: 2011/65/EU
(RoHS2) and 1907/2006 (REACH)
EC DECLARATION OF CONFORMITY
WASTE OF ELECTRICAL AND ELECTRONIC EQUIPMENT
(WEEE)
