INSTALLATION MANUAL
WMM450 METAL IN-CEILING/WALL SPEAKER BACK-BOX
STEP 1 STEP 2
Install the back box onto the supporting beams in the
wall or ceiling. The back box can be installed in both
horizontal or vertical direction. Use the provided slots
for mounting the back box to the supporting beams.
Depending on the structural material the appropriate
fasteners shall be used.
Assemble the cable gland through one of the provided
knock-out holes in the back box, and provide the cable
through it. Loop the cable through the bracket on
top of the back-box, to avoid stress on the cable and
contacts. Make sure the cable gland is well tightened
to avoid any air-leakage through it.
STEP 3
Finish the structure by placing finishing board
(plasterboard, wood, ... ) in front of it. Make the cut-out
for the installed speaker according to the required
dimensions. Afterwards, connect, insert and install
the speaker into the provided opening.
DIMENSIONS
406 mm (16”)406 mm (16”)406 mm (16”)
171
/2“ (446 mm)
171
/8“ (435 mm)
141/
8“ (359 mm)
5”
(127 mm)
177
/8“
(455 mm)
The WEEE marking indicates that this product
should not be disposed with regular household
waste at the end of its product life. This regulation
is created to protect both the environment and
human health.
This product is developed and manufactured with
high quality materials and components which can
be recycled and/or reused. Please dispose of this
product at your local collection point or recycling
center for electrical and electronic waste. Do this
to make sure that the product is recycled in an
environmental friendly way, and help to protect
the environment in which we all live.
INSTALLATION MANUAL
WMM450 METAL IN-CEILING/WALL SPEAKER BACK-BOX
•
IF THERE IS ANY DAMAGE TO THE CARTON BOX
OR THE UNIT ITSELF, INFORM YOUR VENDOR
IMMEDIATELY.
•
ALWAYS FOLLOW THE LOCAL REGULATIONS AND
REQUIREMENTS REGARDING INSTALLATION,
SUSPENSION AND CONNECTION OF THIS
LOUDSPEAKER. EVEN WHEN OTHERWISE SPECIFIED
IN THIS DOCUMENT.
• THE INSTALLATION OF THIS LOUDSPEAKER SHALL
BE DONE BY QUALIFIED PERSONNEL ONLY.
•
ALWAYS KEEP THESE INSTRUCTIONS FOR FUTURE
REFERENCE. NEVER THROW THEM AWAY
• ALWAYS HANDLE THIS UNIT WITH CARE
• CLEAN ONLY WITH DRY CLOTH
•
HEED ALL WARNINGS AND FOLLOW ALL
INSTRUCTIONS
•
NEVER EXPOSE THIS EQUIPMENT TO RAIN,
MOISTURE, ANY DRIPPING OR SPLASHING LIQUID.
•
DO NOT INSTALL THIS UNIT NEAR ANY HEAT
SOURCES SUCH AS RADIATORS OR OTHER
APPARATUS THAT PRODUCE HEAT
•
DO NOT PLACE THIS UNIT IN ENVIRONMENTS
WITH A HIGH LEVEL OF DUST, HEAT, MOISTURE OR
VIBRATION
• THIS UNIT IS DEVELOPED FOR INDOOR USE ONLY.
DO NOT USE IT OUTDOORS
•
ONLY USE ATTACHMENTS & ACCESSORIES SPECIFIED
BY THE MANUFACTURER.
•
ONLY INSTALL THE SPEAKER IN LOCATIONS THAT
CAN STRUCTURALLY SUPPORT THE WEIGHT OF THE
SPEAKER. IGNORING THIS CAN BRING THE SPEAKER
DOWN.
•
DO NOT USE ANY OTHER METHOD THAN SPECIFIED
TO MOUNT THE SPEAKER. IF EXTREME FORCE IS
APPLIED TO THE SPEAKER, IT COULD FALL DOWN
•
ATTACH A SAFETY WIRE TO THE SPEAKER WHEN
IT IS MOUNTED HIGH UP. ONLY USE INDUSTRY-
ACCEPTED RIGGING TOOLS AND METHODS
• CAREFULLY CHECK THE UNIT’S CONDITION AFTER
UNPACKING.
PRECAUTIONS
This product contains no user serviceable parts.
Refer all servicing to qualied service personnel. Do
not perform any servicing (unless you are qualied
to do so.)
CAUTION - SERVICING
This product conforms to all the essential
requirements and further relevant specications
described in following directives: 2011/65/EU
(RoHS2) and 1907/2006 (REACH)
EC DECLARATION OF CONFORMITY
WASTE OF ELECTRICAL AND ELECTRONIC EQUIPMENT
(WEEE)
