Asrock Z790 Pro RS WiFi Bedienungsanleitung
Asrock
Moederbord
Z790 Pro RS WiFi
Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung für Asrock Z790 Pro RS WiFi (64 Seiten) in der Kategorie Moederbord. Dieser Bedienungsanleitung war für 5 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet
Seite 1/64
Contact Information
If you need to contact ASRock or want to know more about ASRock, you’re welcome
to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer
for further information. For technical questions, please submit a support request
form at https://event.asrock.com/tsd.asp
ASRock Incorporation
e-mail: info@asrock.com.tw
ASRock EUROPE B.V.
e-mail: sales@asrock.nl
ASRock America, Inc.
e-mail: sales@asrockamerica.com
Scan the QR code to view more manuals and documents.
Contents
Chapter 1 Introduction 1
1.1 Package Contents 1
1.2 Specications 2
1.3 Motherboard Layout 6
1.4 I/O Panel 9
1.5 Block Diagram 10
1.6 802.11ax Wi-Fi 6E Module and ASRock WiFi 2.4/5/6 GHz
Antennas 11
Chapter 2 Installation 13
2.1 Installing the CPU 14
2.2 Installing the CPU Fan and Heatsink 16
2.3 Installing Memory Modules (DIMM) 17
2.4 Connecting the Front Panel Header 19
2.5 Installing the Motherboard 20
2.6 Installing SATA Drives 21
2.7 Installing a Graphics Card 23
2.8 Connecting Peripheral Devices 25
2.9 Connecting the Power Connectors 26
2.10 Power On 27
2.11 Jumpers Setup 28
2.12 Onboard Headers and Connectors 29
2.13 Post Status Checker 46
