Asrock Z390 Taichi Ultimate Bedienungsanleitung

Asrock Hauptplatine Z390 Taichi Ultimate

Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung für Asrock Z390 Taichi Ultimate (110 Seiten) in der Kategorie Hauptplatine. Dieser Bedienungsanleitung war für 16 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet

Download PDF

Seite 1/110

Version 1.0

Published July 2018

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian

Consumer Law. You are entitled to a replacement or refund for a major failure and

compensation for any other reasonably foreseeable loss or damage caused by our

goods. You are also entitled to have the goods repaired or replaced if the goods fail

to be of acceptable quality and the failure does not amount to a major failure. If

you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard

International call charges apply)

e terms HDMI and HDMI High-Denition Multimedia Interface, and the HDMI ®

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535;

7,003,467 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, &

DTS and the Symbol together is a registered trademark & DTS Connect, DTS Interactive,

DTS Neo:PC are trademarks of DTS, Inc. Product includes soware.

Produktspezifikationen

Marke:	Asrock
Kategorie:	Hauptplatine
Modell:	Z390 Taichi Ultimate
Prozessorhersteller:	Intel
WLAN:	Ja
WLAN-Standards:	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth:	Ja
Bluetooth-Version:	5.0
Breite:	305 mm
Tiefe:	244 mm
Mitgelieferte Kabel:	SATA
Eingebauter Ethernet-Anschluss:	Ja
Zertifizierung:	FCC, CE, ErP/EuP
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	3
Warentarifnummer (HS):	84733020
Anzahl HDMI-Anschlüsse:	1
Audio Kanäle:	7.1 Kanäle
Unterstützt Windows-Betriebssysteme:	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64
RAID Level:	0, 1,5, 10
USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A:	4
Schnellinstallationsanleitung:	Ja
Prozessorsockel:	LGA 1151 (Socket H4)
Intel® Turbo-Boost-Technologie:	2.0
Kompatible Prozessoren:	Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9
Motherboardformfaktor:	ATX
Motherboard Chipsatz Familie:	Intel
Motherboard Chipsatz:	Intel Z390
Komponente für:	PC
PC Gesundheitsüberwachung:	CPU, FAN, Temperature, Voltage
Unterstützte Arbeitsspeicher:	DDR4-SDRAM
Anzahl der Speichersteckplätze:	4
Arbeitsspeicher Typ:	DIMM
Speicherkanäle:	Zweikanalig
ECC:	Ja
Ohne ECC:	Ja
Unterstützte Arbeitsspeichergeschwindigkeit:	2133,2400,2666,2800,2933,3200,3600,3733,3800,3866,4000,4133,4200 MHz
RAM-Speicher maximal:	64 GB
Anzahl der M.2 (M)-Steckplätze:	2
PCI-Express x16 (Gen 3.x)-Anschlüsse:	3
DirectX-Version:	12.0
Maximale Auflösung:	4096 x 2160 Pixel
Parallele Verarbeitungstechnologie:	3-Way CrossFireX, CrossFireX, NVLink, Quad-GPU CrossFireX, Quad-GPU SLI, SLI
Treiber enthalten:	Ja
Anzahl PS/2 Anschlüsse:	1
ATX Stromstecker (24-pol.):	Ja
SATA III Anschlüsse:	6
Anzahl USB 2.0 Schnittstellen:	2
CPU Ventilatorstecker:	Ja
Zahl der Chassisventilatorstecker:	6
Front Panel Audiostecker:	Ja
TPM-Verbinder:	Ja
RGB-LED-Stiftleiste:	Ja
USB 3.2 Gen 1 (3.1 Gen 1) Anschlüsse:	2
BIOS-Speichergröße:	256 Mbit
BIOS-Typ:	UEFI AMI
ACPI-Version:	6.0
Systemverwaltung BIOS (SMBIOS) Version:	2.7
Ethernet Schnittstellen Typ:	Gigabit Ethernet
LAN-Controller:	Intel I211-AT, Intel I219-V
Mitgelieferte Software:	ASRock A-Tuning, ASRock Polychrome RGB, ASRock XFast LAN
USB 3.2 Gen 2 (3.1 Gen 2) Anzahl der Anschlüsse vom Typ A:	3
Eingebaute Grafikadapter:	Ja
USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ C:	1
Anzahl DisplayPort Anschlüsse:	1
S/PDIF-Ausgang:	Ja
Intel® Quick-Sync-Video-Technik:	Ja
Intel® InTru™ 3D Technologie:	Ja
Intel® Clear Video HD Technology für (Intel® CVT HD):	Ja
Unbuffered Speicher:	Ja
Diskreter Grafik support:	Ja
PCI-Express x1 (Gen 3.x)-Anschlüsse:	2
Thunderbolt-Stiftleisten:	1
Intel® Extreme Memory Profile (XMP):	Ja
Intel® Optane™ Memory-bereit:	Ja
Wake-on-LAN bereit:	Ja
DisplayPorts-Version:	1.2
Intel® Insider™:	Ja
Clear-CMOS-Taste:	Ja
EPS Stromstecker (8-pin):	Ja
WiFi-AP-Antennenbuchse:	2
USB 3.2 Gen 2 (3.1 Gen 2) Anschlüsse:	1
Nebenkosten inklusive:	Ja
Anzahl der M.2 (E) Slots:	1
