User Manual
Version 1.0
Published June 2013
Copyright©2013 ASRock INC. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identiîcation or explanation and to the ownersâ beneît, without intent to
infringe.
Disclaimer:
Speciîcations and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock. ASRock assumes no responsibility for
any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or îtness for a particular
purpose.
In no event shall ASRock, its directors, oîcers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of proîts, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the documentation or product.
îis device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
îe Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
âPerchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorateâ
ASRock Website: http://www.asrock.com
Contents
Chapter 1 Introduction 1
1.1 Package Contents 1
1.2 Speciîcations 2
1.3 Unique Features 6
1.4 Motherboard Layout 10
1.5 I/O Panel 12
1.6 WiFi-802.11n Module and ASRock WiFi 2.4GHz Antenna 14
Chapter 2 Installation 15
2.1 Installing the CPU 16
2.2 Installing the CPU Fan and Heatsink 19
2.3 Installing Memory Modules (DIMM) 20
2.4 Expansion Slots (PCI and PCI Express Slots) 22
2.5 Jumpers Setup 23
2.6 Onboard Headers and Connectors 24
Chapter 3 Software and Utilities Operation 28
3.1 Installing Drivers 28
3.2 A-Tuning 29
3.3 IntelÂź Rapid Start Technology 33
3.4 IntelÂź Smart Connect Technology 38
3.5 IntelÂź Remote Wake Technology 43
3.5.1 Conîguring and Using MeshCentral 43
3.5.2 Conîguring and Using Splashtop 48
3.6 Start8 51
