Version 1.1
Published November 2014
Copyright©2014 ASRock INC. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identication or explanation and to the owners’ benet, without intent to
infringe.
Disclaimer:
Specications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock. ASRock assumes no responsibility for
any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or tness for a particular
purpose.
In no event shall ASRock, its directors, ocers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of prots, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the documentation or product.
is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlorate”
ASRock Website: http://www.asrock.com
Contents
1. Introduction ................................................................ 1
1.1 Package Contents ..................................................................... 1
1.2 Specications ............................................................................. 2
1.3 Motherboard Layout ................................................................. 5
1.4 I/O Panel .................................................................................. 7
2. Installation .................................................................. 9
Pre-installation Precautions ................................................................ 9
2.1 CPU Installation ......................................................................... 10
2.2 Installation of CPU Fan and Heatsink ...................................... 11
2.3 Installation of Memory Modules (DIMM) .................................... 12
2.4 Expansion Slots (PCI Express Slots) ......................................... 14
2.5 Jumpers Setup ........................................................................... 15
2.6 Onboard Headers and Connectors ....................................... 16
2.7 Dual Graphics Operation Guide ................................................ 20
3. Software and Utilities Operation ............................... 22
3.1 Installing Drivers ........................................................................ 22
3.2 A-Tuning .................................................................................... 23
3.3 ASRock APP Shop .................................................................... 29
3.4 Start8 ......................................................................................... 35
4. UEFI SETUP UTILITY .................................................. 38
4.1 Introduction ................................................................................ 38
4.1.1 UEFI Menu Bar ................................................................ 38
4.1.2 Navigation Keys ............................................................... 39
4.2 Main Screen ............................................................................... 39
4.3 OC Tweaker Screen................................................................... 40
4.4 Advanced Screen ...................................................................... 43
4.4.1 CPUConguration ........................................................... 44
4.4.2 NorthBridgeConguration .............................................. 45
4.4.3 SouthBridgeConguration ............................................. 46
4.4.4 StorageConguration ...................................................... 47
4.4.5 ACPIConguration .......................................................... 48
4.4.6 USBConguration ........................................................... 50
4.4.7 Trusted Computing .......................................................... 51
4.5 Tool ............................................................................................ 52
4.6 Hardware Health Event Monitoring Screen ............................... 55
4.7 Boot Screen ............................................................................... 56
4.8 Security Screen ......................................................................... 58
4.9 Exit Screen ................................................................................ 59
