Seite 1/90
Version 1.0
Published January 2017
Copyright©2017 ASRock INC. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identication or explanation and to the owners’ benet, without intent to
infringe.
Disclaimer:
Specications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock. ASRock assumes no responsibility for
any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or tness for a particular
purpose.
In no event shall ASRock, its directors, ocers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of prots, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the documentation or product.
is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”
ASRock Website: http://www.asrock.com
AUSTRALIA ONLY
Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for
any other reasonably foreseeable loss or damage caused by our goods. You are also entitled
to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure. If you require assistance please call ASRock Tel
: +886-2-28965588 ext.123 (Standard International call charges apply)
Who knew that at age 19, I would be a World Champion PC gamer. When I was 13, I actually
played competitive billiards in professional tournaments and won four or ve games o guys
who played at the highest level. I actually thought of making a career of it, but at that young
age situations change rapidly. Because I’ve been blessed with great hand-eye coordination and
a grasp of mathematics (an important element in video gaming) I gravitated to that activity.
GOING PRO
I started professional gaming in 1999 when I entered the CPL (Cyberathlete Professional
League) tournament in Dallas and won $4,000 for coming in third place. Emerging as one
of the top players in the United States, a company interested in sponsoring me ew me to
Sweden to compete against the top 12 players in the world. I won 18 straight games, lost
none, and took rst place, becoming the number one ranked Quake III player in the world
in the process. Two months later I followed that success by traveling to Dallas and defending
my title as the world’s best Quake III player, winning the $40,000 grand prize. From there
I entered competitions all over the world, including Singapore, Korea, Germany, Australia,
Holland and Brazil in addition to Los Angeles, New York and St. Louis.
WINNING STREAK
I was excited to showcase my true gaming skills when defending my title as CPL
Champion of the year at the CPL Winter 2001 because I would be competing in a totally
dierent rst person shooter (fps) game, Alien vs. Predator II. I won that competition and
walked away with a new car. e next year I won the same title playing Unreal Tournament
2003, becoming the only three-time CPL champion of the year. And I did it playing a
different game each year, something no one else has ever done and a feat of which I am
extremely proud.
At QuakeCon 2002, I faced o against my rival ZeRo4 in one of the most highly
anticipated matches of the year, winning in a 14 to (-1) killer victory. Competing at Quakecon
2004, I became the World’s 1st Doom3 Champion by defeating Daler in a series of very
challenging matches and earning $25,000 for the victory.
Since then Fatal1ty has traveled the globe to compete against the best in the world, winning
prizes and acclaim, including the 2005 CPL World Tour Championship in New York City for
a $150,000 rst place triumph. In August 2007, Johnathan was awarded the rst ever Lifetime
Achievement Award in the four year history of the eSports-Award for “showing exceptional
sportsmanship, taking part in shaping eSports into what it is today and for being the prime
representative of this young sport. He has become the gurehead for eSports worldwide”.
Fatal1ty Story
LIVIN’ LARGE
Since my rst big tournament wins, I have been a “Professional Cyberathlete”, traveling the
world and livin’ large with lots of International media coverage on outlets such as MTV,
ESPN and a 60 Minutes segment on CBS to name only a few. It's unreal - it's crazy. I’m living
a dream by playing video games for a living. I’ve always been athletic and took sports like
hockey and football very seriously, working out and training hard. is discipline helps me
become a better gamer and my drive to be the best has opened the doors necessary to become
a professional.
A DREAM
Now, another dream is being realized – building the ultimate gaming computer, made
up of the best parts under my own brand. Quality hardware makes a huge difference in
competitions…a couple more frames per second and everything gets really nice. It’s all about
getting the computer processing faster and allowing more uid movement around the maps.
My vision for Fatal1ty hardware is to allow gamers to focus on the game without worrying
about their equipment, something I’ve preached since I began competing. I don’t want to
worry about my equipment. I want to be there – over and done with - so I can focus on
the game. I want it to be the fastest and most stable computer equipment on the face of the
planet, so quality is what Fatal1ty Brand products represent.
Johnathan “Fatal1ty” Wendel
e Fatal1ty name, Fatal1ty logos and the Fatal1ty likeness are registered trademarks of Fatal1ty, Inc., and are used
under license. © 2015 Fatal1ty, Inc. All rights reserved. All other trademarks are the property of their respective
owners.
Contents
Chapter 1 Introduction 1
1.1 Package Contents 1
1.2 Specications 2
1.3 Motherboard Layout 7
1.4 I/O Panel 9
Chapter 2 Installation 11
2.1 Installing the CPU 12
2.2 Installing the CPU Fan and Heatsink 14
2.3 Installing Memory Modules (DIMM) 23
2.4 Expansion Slots (PCI Express Slots) 25
2.5 Jumpers Setup 26
2.6 Onboard Headers and Connectors 27
2.7 Smart Switches 32
2.8 Dr. Debug 33
2.9 SLITM and Quad SLITM Operation Guide 35
2.9.1 Installing Two SLITM-Ready Graphics Cards 35
2.9.2 Driver Installation and Setup 37
2.10 CrossFireXTM and Quad CrossFireXTM Operation Guide 38
2.10.1 Installing Two CrossFireXTM-Ready Graphics Cards 38
2.10.2 Driver Installation and Setup 40
2.11 M.2_SSD (NGFF) Module Installation Guide (M2_1) 41
2.12 M.2_SSD (NGFF) Module Installation Guide (M2_2) 45
Chapter 3 Software and Utilities Operation 48
3.1 Installing Drivers 48
3.2 F-Stream 49
3.2.1 Installing F-Stream 49
3.2.2 Using F-Stream 49
3.3 ASRock Live Update & APP Shop 52
3.3.1 UI Overview 52
3.3.2 Apps 53
3.3.3 BIOS & Drivers 56
3.3.4 Setting 57
3.4 Creative SoundBlaster Cinema3 58
3.5 ASRock RGB LED 59
Chapter 4 UEFI SETUP UTILITY 61
4.1 Introduction 61
4.1.1 UEFI Menu Bar 61
4.1.2 Navigation Keys 62
4.2 Main Screen 63
4.3 OC Tweaker Screen 64
4.4 Advanced Screen 66
4.4.1 CPU Conguration 67
4.4.2 North Bridge Conguration 68
4.4.3 South Bridge Conguration 69
4.4.4 Storage Conguration 70
4.4.5 Super IO Conguration 71
4.4.6 ACPI Conguration 72
4.4.7 Trusted Computing 73
4.5 Tools 74
4.6 Hardware Health Event Monitoring Screen 76
4.7 Security Screen 78
4.8 Boot Screen 79
4.9 Exit Screen 81
English
2
1.2 Specications
Platform • ATX Form Factor
CPU • Supports AMD AM4 Socket Ryzen CPUs (Summit Ridge)
• IR Digital PWM
• 16 Power Phase design
• Supports ASRock Hyper BCLK Engine II
Chipset • AMD Promontory X370
Memory • Dual Channel DDR4 Memory Technology
• 4 x DDR4 DIMM Slots
• Supports DDR4 3200+(OC)/2933(OC)/2667/2400/2133 ECC
& non-ECC, un-buered memory*
* Please refer to Memory Support List on ASRock’s website for
more information. (http://www.asrock.com/)
• Max. capacity of system memory: 64GB
• 15μ Gold Contact in DIMM Slots
Expansion
Slot
• 2 x PCI Express 3.0 x16 Slots (single at x16 (PCIE2); dual at
x8 (PCIE2) / p10-x8 (PCIE3))*
* Supports NVMe SSD as boot disks
• 1 x PCI Express 2.0 x16 Slot (PCIE5 @ p10-x4 mode)
* If PCIE5 slot is occupied, M2_2 will be disabled
• 2 x PCI Express 2.0 p10-x1 Slots
• Supports AMD Quad CrossFireXTM and CrossFireXTM
• Supports NVIDIA® Quad SLI
TM and SLITM
• 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-
802.11ac module (on the rear I/O)
• 15μ Gold Contact in VGA PCIe Slot (PCIE2)
Audio • 7.1 CH HD Audio with Content Protection (Realtek
ALC1220 Audio Codec)
• Premium Blu-ray Audio support
• Supports Surge Protection (ASRock Full Spike Protection)
• Nichicon Fine Gold Series Audio Caps
English
3
Fatal1ty X370 Professional Gaming Series
• 120dB SNR DAC with Dierential Amplier
• TI® NE5532 Premium Headset Amplier for Front Panel
Audio Connector (Supports up to 600 Ohm headsets)
• Pure Power-In
• Direct Drive Technology
• PCB Isolate Shielding
• Impedance Sensing on Line Out port
• Individual PCB Layers for R/L Audio Channel
• RGB LED
• Gold Audio Jacks
• 15μ Gold Audio Connector
• Supports Creative SoundBlaster Cinema3
LAN 1 x 5 Gigabit LAN 100/1000/2500/5000 Mb/s (AQUANTIA®
AQC108):
• Supports Wake-On-LAN
• Supports Lightning/ESD Protection
• Supports PXE
1 x Intel Gigabit LAN 10/100/1000 Mb/s (1 x Intel® I211AT):
• Supports Wake-On-LAN
• Supports Lightning/ESD Protection
• Supports Energy Ecient Ethernet 802.3az
• Supports PXE
Wireless
LAN
• Intel® 802.11ac WiFi Module (Free Bundle)
• Supports IEEE 802.11a/b/g/n/ac
• Supports Dual-Band (2.4/5 GHz)
• Supports high speed wireless connections up to 433Mbps
• Supports Bluetooth 4.2 / 3.0 + High speed class II
Rear Panel
I/O
• 2 x Antenna Ports
• 1 x PS/2 Mouse/Keyboard Port (with Y-cable support)
• 1 x Optical SPDIF Out Port
• 1 x USB 3.1 Type-A Port (10 Gb/s) (Supports ESD Protection)
• 1 x USB 3.1 Type-C Port (10 Gb/s) (Supports ESD Protection)
English
4
* Ultra USB Power is supported on USB3_5_6 ports.
* ACPI wake-up function is not supported on USB3_5_6 ports.
• 6 x USB 3.0 Ports (Supports ESD Protection)
* 1 x Fatal1ty Mouse Port (USB 3.0) is included
• 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED
LED)
• 1 x Clear CMOS Switch
• HD Audio Jacks: Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone (Gold Audio Jacks)
Storage • 8 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
• 2 x SATA3 6.0 Gb/s Connectors by ASMedia ASM1061, sup-
port NCQ, AHCI and Hot Plug
• 1 x Ultra M.2 Socket (M2_1), supports type 2242/2260/2280
M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module
up to Gen3 p12-x4 (32 Gb/s)*
• 1 x M.2 Socket (M2_2), supports type 2230/2242/2260/2280
M.2 PCI Express module up to Gen2 p12-x4 (20 Gb/s)*
* If M2_2 is occupied, PCIE5 slot will be disabled
* Supports NVMe SSD as boot disks
* Supports ASRock U.2 Kit
Connector • 1 x COM Port Header
• 1 x TPM Header
• 1 x Power LED and Speaker Header
• 1 x AMD Fan LED Header
• 2 x RGB LED Headers
* Supports up to 12V/3A, 36W LED Strip
• 1 x CPU Fan Connector (4-pin)
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
• 1 x CPU Optional/Water Pump Fan Connector (4-pin)
(Smart Fan Speed Control)
* e CPU Optional/Water Pump Fan supports the water cooler
fan of maximum 1.5A (18W) fan power.
• 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed
Control)
English
5
Fatal1ty X370 Professional Gaming Series
• 1 x Chassis Optional/Water Pump Fan Connector (4-pin)
(Smart Fan Speed Control)
* e Chassis Optional/Water Pump Fan supports the water
cooler fan of maximum 1.5A (18W) fan power.
* CPU_FAN1, CHA_FAN1, CHA_FAN2 can auto detect if 3-pin
or 4-pin fan is in use.
• 1 x 24 pin ATX Power Connector (Hi-Density Power
Connector)
• 1 x 8 pin 12V Power Connector (Hi-Density Power
Connector)
• 1 x Front Panel Audio Connector (15μ Gold Audio
Connector)
• 1 x AMD LED Fan USB Header
• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports
ESD Protection)
• 2 x USB 3.0 Headers (Support 4 USB 3.0 ports) (Supports
ESD Protection)
• 1 x Dr. Debug with LED
• 1 x Power Switch with LED
• 1 x Reset Switch with LED
BIOS
Feature
• AMI UEFI Legal BIOS with multilingual GUI support
• Supports “Plug and Play”
• ACPI 5.1 compliance wake up events
• Supports jumperfree
• SMBIOS 2.3 support
• CPU, VCORE_NB, DRAM, VPPM, PCH 1.05V, +1.8V,
VDDP, PROM 2.5V, Voltage Multi-adjustment
Hardware
Monitor
• Temperature Sensing: CPU, CPU Optional/Water Pump,
Chassis, Chassis Optional/Water Pump Fans
• Fan Tachometer: CPU, CPU Optional/Water Pump, Chassis,
Chassis Optional/Water Pump Fans
• Quiet Fan (Auto adjust chassis fan speed by CPU tempera-
ture): CPU, CPU Optional/Water Pump, Chassis, Chassis
Optional/Water Pump Fans
• Fan Multi-Speed Control: CPU, CPU Optional/Water Pump,
Chassis, Chassis Optional/Water Pump Fans
English
6
• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, VCORE_
NB, DRAM, PCH 1.05V, +1.8V, VDDP
OS • Microso® Windows® 10 64-bit
* For the updated Windows® 10 driver, please visit ASRock’s
website for details: http://www.asrock.com
Certica-
tions
• FCC, CE, WHQL
• ErP/EuP ready (ErP/EuP ready power supply is required)
Please realize that there is a certain risk involved with overclocking, including adjusting
the setting in the BIOS, applying Untied Overclocking Technology, or using third-party
overclocking tools. Overclocking may aect your system’s stability, or even cause damage to
the components and devices of your system. It should be done at your own risk and expense.
We are not responsible for possible damage caused by overclocking.
* For detailed product information, please visit our website:
http://www.asrock.com
English
8
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 CPU Fan / Waterpump Fan Connector (CPU_OPT/W_PUMP)
3 CPU Fan Connector (CPU_FAN1)
4 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
5 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
6 ATX Power Connector (ATXPWR1)
7 USB 3.0 Header (USB3_9_10)
8 USB 3.0 Header (USB3_7_8)
9 AMD LED Fan USB Header (USB_5)
10 AMD Fan LED Header (AMD_FAN_LED1)
11 Chassis Fan Connector (CHA_FAN1)
12 SATA3 Connectors (SATA3_1_2)
13 SATA3 Connectors (SATA3_3_4)
14 SATA3 Connectors (SATA3_5_6)
15 SATA3 Connectors (SATA3_7_8)
16 SATA3 Connectors (SATA3_A1_A2)
17 Clear CMOS Jumper (CLRMOS1)
18 System Panel Header (PANEL1)
19 Power Switch (PWRBTN1)
20 Reset Switch (RSTBTN1)
21 USB 2.0 Header (USB_1_2)
22 USB 2.0 Header (USB_3_4)
23 Power LED and Speaker Header (SPK_PLED1)
24 Chassis Fan Connector (CHA_FAN2)
25 RGB LED Header (RGB_LED1)
26 RGB LED Header (RGB_LED2)
27 TPM Header (TPMS1)
28 COM Port Header (COM1)
29 Front Panel Audio Header (HD_AUDIO1)
30 Chassis Fan / Waterpump Fan Connector (CHA_FAN3/W_PUMP)
English
10
** ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.
Activity / Link LED Speed LED
Status StatusDescription Description
O No Link Orange 100Mbps/1Gbps/2.5Gbps
connection
Blinking Data Activity
On Link Green 5Gbps connection
*** If you use a 2-channel speaker, please connect the speaker’s plug into “Front Speaker Jack”. See the table below
for connection details in accordance with the type of speaker you use.
Audio Output
Channels
Front Speaker
(No. 7)
Rear Speaker
(No. 5)
Central / Bass
(No. 4)
Line In
(No. 6)
2V -- -- --
4V V -- --
6V V V --
8V V V V
**** ACPI wake-up function is not supported on USB3_ 5_6 ports.
ACT/LINK LED
SPEED LED
LAN Port
English
11
Fatal1ty X370 Professional Gaming Series
is is a ATX form factor motherboard. Before you install the motherboard, study
the conguration of your chassis to ensure that the motherboard ts into it.
Pre-installation Precautions
Take note of the following precautions before you install motherboard components
or change any motherboard settings.
• Make sure to unplug the power cord before installing or removing the motherboard.
Failure to do so may cause physical injuries to you and damages to motherboard
components.
• In order to avoid damage from static electricity to the motherboard’s components,
NEVER place your motherboard directly on a carpet. Also remember to use a grounded
wrist strap or touch a safety grounded object before you handle the components.
• Hold components by the edges and do not touch the ICs.
• Whenever you uninstall any components, place them on a grounded anti-static pad or
in the bag that comes with the components.
• When placing screws to secure the motherboard to the chassis, please do not over-
tighten the screws! Doing so may damage the motherboard.
Chapter 2 Installation
English
12
2.1 Installing the CPU
Unplug all power cables before installing the CPU.
2
1
English
13
Fatal1ty X370 Professional Gaming Series
3
English
14
2.2 Installing the CPU Fan and Heatsink
Aer you install the CPU into this motherboard, it is necessary to install a larger
heatsink and cooling fan to dissipate heat. You also need to spray thermal grease
between the CPU and the heatsink to improve heat dissipation. Make sure that the
CPU and the heatsink are securely fastened and in good contact with each other.
Installing the CPU Box Cooler SR1
Please turn o the power or remove the power cord before changing a CPU or heatsink.
1
2
English
17
Fatal1ty X370 Professional Gaming Series
3
English
19
Fatal1ty X370 Professional Gaming Series
Installing the AM4 Box Cooler SR3
1
2
English
20
3
4
English
21
Fatal1ty X370 Professional Gaming Series
5
CPU_
FAN1
English
24
1
2
3
e DIMM only ts in one correct orientation. It will cause permanent damage to
the motherboard and the DIMM if you force the DIMM into the slot at incorrect
orientation.
English
29
Fatal1ty X370 Professional Gaming Series
1
In tA_ PB_ D+
Du mm y
In tA_ PB_ D-
GND
In tA_ PB_ SSTX+
GND
In tA_ PB_ SSTX-
In tA_ PB_ SSRX+
In tA_ PB_ SSRX-
Vbu sVbu s
Vbu s
In tA_ PA_ S S RX-
In tA_ PA_ S S RX+
GND
In tA_ PA_ S S TX-
In tA_ PA_ S S TX+
GND
In tA_ PA_ D-
In tA_ PA_ D+
USB 3.0 Header
(19-pin USB3_7_8)
(see p.7, No. 8)
(19-pin USB3_9_10)
(see p.7, No. 7)
Besides four USB 3.0 ports
on the I/O panel, there
are two headers on this
motherboard. Each USB
3.0 header can support
two ports.
Front Panel Audio Header
(9-pin HD_AUDIO1)
(see p.7, No. 29)
is header is for
connecting audio devices
to the front audio panel.
Chassis Fan Connectors
(4-pin CHA_FAN1)
(see p.7, No. 11)
(4-pin CHA_FAN2)
(see p.7, No. 24)
Please connect fan cables
to the fan connectors and
match the black wire to
the ground pin.
J_SENSE
OUT2_L
1
MIC_RET
PRESENCE#
GND
OUT2_R
MIC2_R
MIC2_L
OUT_RET
1. High Denition Audio supports Jack Sensing, but the panel wire on the chassis must sup-
port HDA to function correctly. Please follow the instructions in our manual and chassis
manual to install your system.
2. If you use an AC’97 audio panel, please install it to the front panel audio header by the
steps below:
A. Connect Mic_ IN (MIC) to MIC2_L.
B. Connect Audio_R (RIN) to OUT2_R and Audio_L (LIN) to OUT2_L.
C. Connect Ground (GND) to Ground (GND).
D. MIC_RET and OUT_RET are for the HD audio panel only. You don’t need to connect
them for the AC’97 audio panel.
E. To activate the front mic, go to the “FrontMic” Tab in the Realtek Control panel and
adjust “Recording Volume”.
GND
FAN_V OLTAG E
CHA_FAN_SPEED
FAN_SPEED_CONTROL 4
3
2
1
GN D
FAN_SPE ED
FAN_SPE ED_CONTRO L
FAN_VOLTAGE
1 2 3 4
English
32
2.7 Smart Switches
e motherboard has three smart switches: Power Switch, Reset Switch and Clear
CMOS Switch, allowing users to quickly turn on/o the system, reset the system
and clear the CMOS values.
Power Switch
(PWRBTN)
(see p.7, No. 19)
Power Switch allows users
to quickly turn on/o the
system.
Reset Switch
(RSTBTN)
(see p.7, No. 20)
Reset Switch allows
users to quickly reset the
system.
Clear CMOS Switch
(CLRCBTN)
(see p.9, No. 17)
Clear CMOS Switch
allows users to quickly
clear the CMOS values.
Power
Reset
is function is workable only when you power o your computer and unplug the power
supply.
Produktspezifikationen
Marke: | Asrock |
Kategorie: | Hauptplatine |
Modell: | Fatal1ty X370 Gaming |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Asrock Fatal1ty X370 Gaming benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Hauptplatine Asrock
15 Oktober 2024
4 Oktober 2024
4 Oktober 2024
2 Oktober 2024
26 September 2024
22 September 2024
22 September 2024
17 September 2024
8 September 2024
3 September 2024
Bedienungsanleitung Hauptplatine
- Hauptplatine Asus
- Hauptplatine Gigabyte
- Hauptplatine Sharkoon
- Hauptplatine MSI
- Hauptplatine Supermicro
- Hauptplatine NZXT
- Hauptplatine ECS
- Hauptplatine EPoX
- Hauptplatine Evga
- Hauptplatine Intel
- Hauptplatine Abit
- Hauptplatine Elitegroup
- Hauptplatine Foxconn
- Hauptplatine Biostar
Neueste Bedienungsanleitung für -Kategorien-
7 Oktober 2024
5 Oktober 2024
27 September 2024
24 September 2024
19 September 2024
17 September 2024
16 September 2024
15 September 2024
13 September 2024
12 September 2024
