Seite 1/72
ASRock A790GX/128M Motherboard
No part of this installation guide may be reproduced, transcribed, transmitted, or trans-
lated in any language, in any form or by any means, except duplication of documen-
tation by the purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this guide may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identifica-
tion or explanation and to the owners’ benefit, without intent to infringe.
Specifications and information contained in this guide are furnished for informational
use only and subject to change without notice, and should not be constructed as a
commitment by ASRock. ASRock assumes no responsibility for any errors or omissions
that may appear in this guide.
With respect to the contents of this guide, ASRock does not provide warranty of any kind,
either expressed or implied, including but not limited to the implied warranties or
conditions of merchantability or fitness for a particular purpose. In no event shall
ASRock, its directors, officers, employees, or agents be liable for any indirect, special,
incidental, or consequential damages (including damages for loss of profits, loss of
business, loss of data, interruption of business and the like), even if ASRock has been
advised of the possibility of such damages arising from any defect or error in the guide
or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Published January 2009
Copyright©2009 ASRock INC. All rights reserved.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic
substance controlled in Perchlorate Best Management Practices (BMP) regulations
passed by the California Legislature. When you discard the Lithium battery in
California, USA, please follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlorate”
ASRock Website: http://www.asrock.com
ASRock A790GX/128M Motherboard
1 PS2_USB_PW1 Jumper 21 Chassis Speaker Header
2 ATX 12V Power Connector (ATX12V1) (SPEAKER 1, Purple)
3 CPU Heatsink Retention Module 22 Chassis Fan Connector (CHA_FAN1)
4 AM2 940-Pin CPU Socket 23 USB 2.0 Header (USB8_9, Blue)
5 CPU Fan Connector (CPU_FAN1) 24 USB 2.0 Header (USB6_7, Blue)
6 2 x 240-pin DDR2 DIMM Slots 25 SPI Flash Memory (8Mb)
(Dual Channel A: DDRII_1, DDRII_2; Yellow) 26 USB 2.0 Header (USB10_11, Blue)
7 2 x 240-pin DDR2 DIMM Slots 27 Infrared Module Header (IR1)
(Dual Channel B: DDRII_3, DDRII_4; Orange) 28 Floppy Connector (FLOPPY1)
8 ATX Power Connector (ATXPWR1) 29 Serial Port Connector (COM1)
9 Primary IDE Connector (IDE1, Blue) 30 Front Panel Audio Header
10 North Bridge Fan Connector (NB_FAN1) (HD_AUDIO1, Lime)
11 Clear CMOS Jumper (CLRCMOS1) 31 Internal Audio Connector: CD1 (Black)
12 PCI Express p2-x1 Slot (PCIE3; Green) 32 HDMI_SPDIF Header
13 Southbridge Controller (HDMI_SPDIF1, Yellow)
14 Fifth SATAII Connector (SATAII_5, Red) 33 PCI Slots (PCI1- 2)
15 Sixth SATAII Connector (SATAII_6, Red) 34 PCI Express 2.0 x16 Slot
16 Primary SATAII Connector (SATAII_1, Red) (PCIE2; Orange)
17 Third SATAII Connector (SATAII_3, Red) 35 PCI Express 2.0 x16 Slot (PCIE1; Green)
18 Fourth SATAII Connector (SATAII_4, Red) 36 Northbridge Controller
19 System Panel Header (PANEL1, Orange) 37 Power Fan Connector (PWR_FAN1)
20 Secondary SATAII Connector (SATAII_2, Red)
ASRock A790GX/128M Motherboard
** If you use 2-channel speaker, please connect the speaker’s plug into “Front Speaker Jack”.
See the table below for connection details in accordance with the type of speaker you use.
TABLE for Audio Output Connection
Audio Output Channels Front Speaker Rear Speaker Central / Bass Side Speaker
(No. 8) (No. 5) (No. 6) (No. 4)
2 V -- -- --
4 V V -- --
6 V V V --
8 V V V V
LAN Port
ACT/LINK
LED
SPEED
LED
* There are two LED next to the LAN port. Please refer to the table below for the LAN port LED
indications.
LAN Port LED Indications
Activity/Link LED SPEED LED
Status Description Status Description
Off No Activity Off 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
Green 1Gbps connection
1 PS/2 Mouse Port (Green) ** 8 Front Speaker (Lime)
2 VGA/D-Sub Port 9 Microphone (Pink)
* 3 LAN RJ-45 Port 10 USB 2.0 Ports (USB01)
4 Side Speaker (Gray) 11 USB 2.0 Ports (USB23)
5 Rear Speaker (Black) 12 Optical SPDIF Out Port
6 Central / Bass (Orange) 13 VGA/DVI-D Port
7 Line In (Light Blue) 14 PS/2 Keyboard Port (Purple)
