Seite 1/147
1
ASRock 980DE3/U3S3 R2.0 Motherboard
English
Copyright Notice:
No part of this installation guide may be reproduced, transcribed, transmitted, or trans-
lated in any language, in any form or by any means, except duplication of documentation
by the purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this guide may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identiîšżca-
tion or explanation and to the owners’ benet, without intent to infringe.
Disclaimer:
Speciîšżcations and information contained in this guide are furnished for informational use
only and subject to change without notice, and should not be constructed as a commit-
ment by ASRock. ASRock assumes no responsibility for any errors or omissions that may
appear in this guide.
With respect to the contents of this guide, ASRock does not provide warranty of any kind,
either expressed or implied, including but not limited to the implied warranties or condi-
tions of merchantability or îšżtness for a particular purpose. In no event shall ASRock, its
directors, ofîšżcers, employees, or agents be liable for any indirect, special, incidental, or
consequential damages (including damages for loss of proîšżts, loss of business, loss of
data, interruption of business and the like), even if ASRock has been advised of the pos-
sibility of such damages arising from any defect or error in the guide or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlorate”
ASRock Website: http://www.asrock.com
Published September 2014
Copyright©2014 ASRock INC. All rights reserved.
2
ASRock 980DE3/U3S3 R2.0 Motherboard
English
Motherboard Layout
1 ATX 12V Power Connector (ATX12V1) 20 SATA2 Connector (SATA2_1 (PORT 1))
2 Power Fan Connector (PWR_FAN1) 21 USB 2.0 Header (USB6_7)
3 CPU Fan Connector (CPU_FAN1) 22 USB 2.0 Header (USB4_5)
4 AM3+ CPU Socket 23 USB 2.0 Header (USB8_9)
5 CPU Heatsink Retention Module 24 System Panel Header (PANEL1)
6 2 x 240-pin DDR3 DIMM Slots 25 Power LED Header (PLED1)
(Dual Channel: DDR3_A1, DDR3_B1) 26 Chassis Speaker Header (SPEAKER1)
7 2 x 240-pin DDR3 DIMM Slots 27 Floppy Connector (FLOPPY1)
(Dual Channel: DDR3_A2, DDR3_B2) 28 Internal Audio Connector (CD1)
8 Northbridge Controller 29 Front Panel Audio Header (HD_AUDIO1)
9 SATA3 Connector (SATA3_2 (PORT 7)) 30 HDMI_SPDIF Header (HDMI_SPDIF1)
10 ATX Power Connector (ATXPWR1) 31 Infrared Module Header (IR1)
11 SATA3 Connector (SATA3_1 (PORT 6)) 32 PCI Slots (PCI1-2)
12 Chassis Fan Connector (CHA_FAN1) 33 PCI Express 2.0 p2-x1 Slot (PCIE4)
13 Southbridge Controller 34 PCI Express 2.0 p2-x16 Slot (PCIE3)
14 SPI Flash Memory (16Mb) 35 PCI Express 2.0 p2-x1 Slot (PCIE2)
15 SATA2 Connector (SATA2_6 (PORT 5)) 36 IDE1 Connector (IDE1)
16 SATA2 Connector (SATA2_5 (PORT 4)) 37 PCI Express 2.0 p2-x1 Slot (PCIE1)
17 SATA2 Connector (SATA2_4 (PORT 3)) 38 Clear CMOS Jumper (CLRCMOS1)
18 SATA2 Connector (SATA2_3 (PORT 2)) 39 USB 3.0 Header (USB3_2_3)
19 SATA2 Connector (SATA2_2 (PORT 1))
6 71 2 43 5
8
9
10
11
12
13
14
15
16
17
18
1920212223242526272829
30
31
32
33
34
35
IDE1
AMD
SB710
Chipset
AT X12V 1
8Mb
BIO S
CMO S
BAT TE RY
CLRC MOS 1
1
LAN
PHY
AUD I O
CO D E C
Sup er
I/O
IR1
1
CD1
HD_AU DIO1
1
PCI E1
FLOP PY1
HDLED RES ET
PLED PWRBTN
1
PANEL1
SPEAK ER1
1
SATAII_ 2( POR T 1)
AMD
770
Chipset
PCI1
PCI2
980DE3/ U3S3
SATAII_ 4( POR T 3)
SATAII_ 3( POR T 2)
To p:
LIN E IN
Ce n te r :
FRO NT
Bot t om :
MIC IN
PS2
Mo us e
PS2
Ke yboa rd
US B 2.0
T: USB 0
B: USB 1
Top:
RJ- 45
USB 3.0
T: US B 0
B: US B1
Fr o nt US B 3.0
ErP/EuP Ready
RoHS
USB8 _9
1
SATAII_ 1( POR T 0)
SATAII_ 6( POR T 5)
SATAII_ 5( POR T 4)
1
PLED1
1
HDM I_S PDI F1
USB6 _7
1
USB4 _5
1
USB 2.0
T: US B 2
B: US B3
COM1
CHA_ FAN1
Sup port 8-Cor e CPU
36
37
38
SOCK ET AM3b
PCI E2
PCI E4
PCI E3
DDR3 _A 1 (6 4 bit , 24 0 - pin m od ul e )
DDR3 _A 2 (6 4 bit , 24 0 - pin m od ul e )
DDR3 _B 1 ( 6 4 bit , 2 40 - pin m o d ul e )
DDR3 _B 2 ( 6 4 bit , 2 40 - pin m o d ul e )
SATA3_2 ( POR T 7)
SATA3_1 ( POR T 6)
DDR3 1866
AM3+
140W CPU
CPU _ FAN 1PWR_ FAN 1
X
Fast RAM
XFast LAN
USB3 _2_ 3
39
3
ASRock 980DE3/U3S3 R2.0 Motherboard
English
I/O Panel
LAN Port
ACT/LINK
LED
SPEED
LED
* There are two LED next to the LAN port. Please refer to the table below for the LAN port LED
indications.
LAN Port LED Indications
Activity/Link LED SPEED LED
Status Description Status Description
Off No Link Off 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
On Link Green 1Gbps connection
1 PS/2 Mouse Port (Green) 6 USB 2.0 Ports (USB01)
* 2 LAN RJ-45 Port 7 USB 3.0 Port (USB01)
3 Line In (Light Blue) 8 USB 2.0 Ports (USB23)
** 4 Front Speaker (Lime) 9 Serial Port: COM1
5 Microphone (Pink) 10 PS/2 Keyboard Port (Purple)
** To enable Multi-Streaming function, you need to connect a front panel audio cable to the front
panel audio header. Please refer to below steps for the software setting of Multi-Streaming.
For Windows® XP:
After restarting your computer, you will nd “Mixer” tool on your system. Please select “Mixer
ToolBox” , click “Enable playback multi-streaming”, and click “ok”. Choose “2CH” or
“4CH” and then you are allowed to select “Realtek HDA Primary output” to use Rear Speaker
and Front Speaker, or select “Realtek HDA Audio 2nd output” to use front panel audio. Then
reboot your system.
For Windows® 8.1 / 8 / 7 / VistaTM:
After restarting your computer, please double-click “Realtek HD Audio Manager” on the
system tray. Set “Speaker Conguration” to “Quadraphonic” or “Stereo”. Click “Device
advanced settings”, choose “Make front and rear output devices playbacks two different audio
streams simultaneously”, and click “ok”. Then reboot your system.
5
6
4
1 2
3
78910
