Aegis NVXā¢
AES 256 Bit XTS Military Grade
Hardware-Encrypted NVMe SSD
with USB 10Gbs High Speed
Type-C Connector
Speed, Action.
Finally an encrypted hard
drive that stays well ahead
of your r/w speed demands.
Whether youāre pulling huge
amounts of forensic data in
a tight timeframe or shooting
at your HD Cameraās highest
resolutions and fastest
frame speeds, all of your
data is being encrypted on
its path to storage at speeds
of up to 1000MB/s. And with
5 available PINs, access
to the deviceās contents is
limited to those who are au-
thorized within the workflow.
Built for Anywhere.
Smaller than most smart-
phones, the NVX is built to
go wherever you do, fitting
right into your workspace;
from your pocket, media
case, backpack, and most
media storage cradles. Ex-
treme temperatures, rugged
terrains, and hard knocks
are what itās made for.
Available in 500GB, 1TB,
and 2TB capacities, the NVX
ships with a molded protec-
tive case (not that it needs
one) a C-to-C extension
cable, and a C-to-A adapter
/ extension cable.
Serious Materials.
The crush-resistant enclo-
sure is milled from solid
6061 aircraft-grade alumi-
num alloy, with stainless
breakaway fasteners and
a new moisture resistant
rubberized keypad. Inside,
the components are further
protected with hardened ep-
oxy potting. The rugged inte-
grated USB 10Gbs type-C
connector cable securely
tucks away when not in use.
No Software, No Prob.
Apricornās unique hardware
based approach delivers the
highest levels of data secu-
rity and workflow compati-
bility. Like all Aegis secure
drives, the NVX is soft-
ware-free and hardware-en-
crypted, making it complete-
ly cross-compatible. 100%
of its authentication and
encryption processes take
place within the device itself.
Maximum Data Security at Breakneck Speeds.
The next generation of Aegis Secure Drives incorporates all of the upper
level security features youāve come to expect from Apricorn with a patent-
ed proprietary NVMe architecture to deliver 256-bit hardware encryption
at transfer speeds of up to 1000MB/s.
The Safest Place on Earth for Your Data.
CAPACITIES
NVMe SSD: 500GB, 1TB, 2TB
TRANSFER RATE
NVMe SSD: up to 1000MB/s*
INTERFACE
USB 10Gbps TYPE-C
DIMENSIONS and WEIGHT
67mm x 120mm x 15mm | 184.27g
2.63ā x 4.72ā x 0.59ā | 6.5oz
POWER SUPPLY
100% bus powered
OPERATING TEMPERATURE RANGES
-40Ā° to 158Ā°F (-40Ā°C to 70Ā°C)
OPERATING HUMIDITY RANGES
95% @ temps under 131Ā°F (55Ā°C)
CRUSH RESISTANT
up to 6500 LBS
SHOCK SSD
NON-OPERATING: 1500G .5ms
OPERATING: 1500G .5ms
WARRANTY
3-Year Limited
SYSTEM COMPATIBILITY
WINDOWS, MAC OS, LINUX, ANDROID, CITRIX
any machine that supports a USB mass storage device
SKU NUMBERS
NVMe SSD: ANVX-500, ANVX-1TB, ANVX-2TB
ECCN / HTS / CAGE CODE
5A992.c / 8523.51.0000 / 3VYK8
STANDARDS / CERTIFICATIONS
IP-67
TAA COMPLIANT
PACKAGE CONTENTS
Aegis NVX, C-TO-C Extension Cable
Aegis NVX, C-TO-A Adapter / Extension Cable
Multi-Language Quick-Start Guide
Separate Admin and User Modes / PINs
Admin (Device Conļ¬guration) Mode and User Access
Mode. The Admin mode controls the universal program-
mable settings of the device and can only be accessed
with the Admin PIN. The User mode is for general external
drive usage like read /write, unlock / lock, and certain other
functions. The User mode is accessible via a User PIN or
the Admin PIN. Up to four User PINs may be enrolled.
Admin Forced Enrollment
Eliminates factory default PIN vulnerability by forcing the
enrollment of an Admin PIN prior to use. As with all Apri-
corn Aegis secure devices, there are no default passwords,
and no back-doors. In order to use any Apricorn secure
drive, the Admin must ļ¬rst establish a complex PIN.
User Forced Enrollment
Beyond the admin PIN, one additional PIN can be gen-
erated to access the deviceās data. This User PIN can be
set up by the admin at initial setup, or the device can be
deployed in a state of User Forced Enrollment, allowing the
user to establish his or her own PIN prior to use.
Data Recovery PINs
Programmed by the admin at time of setup to permit
regaining access to the drive by creating a state of User
Forced Enrollment in which a new User PIN can be created
without aļ¬ecting the driveās existing data or the Admin PIN.
Two Read-Only Modes
Universal Read Only: set by the admin from within the
admin mode and canāt be modiļ¬ed or disabled by anyone
but the admin. The second (User) mode can be set and
disabled by a user but can also be enabled or disabled by
the admin.
Programmable PIN Length
Admin Designates Minimum and Maximum PIN Lengths
(between 7 and 16 Characters). The longer the PIN, the
more secure the data on the device becomes. For exam-
ple, the odds of brute force success go from 1/10,000,000
with a 7-digit PIN to 1/100,000,000 with an 8 digit PIN. In
cases where the User sets up his or her own PIN from
User Forced Enrollment, the Admin can still aļ¬ect User
password length requirements
Unattended Auto Lock
Programmable Length of Time of Inactivity Permitted
Before Drive Locks Itself. All Aegis Secure Drives will auto-
matically lock once disconnected from a computerās USB
port or the power to that USB port is interrupted, or after a
pre-programmed period of inactivity.
Lock Override
Allows Drive to Remain Unlocked During USB Port
Re-Enumeration (Virtual Machine, Remote Boot). Desig-
nated for speciļ¬c cases in which the drive needs to remain
unlocked through USB port re-enumeration such as during
reboot, or passing through a virtual machine.
Self-Destruct PIN
When Programmed and Activated, Performs a Crypto-
Erase and Becomes New Access PIN. The last line of de-
fense for data security when the deviceās physical security
is at risk. The Self-Destruct PIN defends against these
physically compromising situations by erasing the driveās
contents, leaving it in normal working order appearing yet
to be deployed.
Brute Force Defense
Programmable Number of Consecutive Invalid PIN
Attempts Permitted (4-20) Before Crypto-Erase. If the
device comes under a physical brute force attack, once the
programmed number (between 4 and 20) of consecutive
incorrect password entries has been attempted, the device
will delete its own encryption key and destroy the ability to
decrypt its stored data.
Provision Lock
Patented setting where the admin can designate whether
the device will permit itself to be reset by a User or after
a brute force attempt. If Provision Lock is enabled, any
attempt at complete reset will ābrickā the device for good.
Our patented ļ¬rmware delivering the industryās most advanced feature setā the heart and soul of every Apricorn device.
Aegis NVXā¢
NVMe SSD with AES 256-Bit XTS Hardware-Encrypted with USB 10Gbps Type-C Connector
Milled from a Solid Block of Aircraft Grade Aluminum with Breakaway Fasteners and Epoxy Threadlock
Wear-Resistant Membrane Style Keypad / 10k Press Tested
Software-Free / Locked-Down Firmware to Prevent Introduction of Malware Such as BadUSB
TECHNICAL SPECIFICATIONS
* To achieve these speeds, your computerās internal hard drive must also be an SSD; all transfer rates will be limited by computerās internal HDD
One gigabyte (GB) = one billion bytes; accessible capacity will be less and actual capacity depends on the operating environment and formatting.
Ā©2023 Apricorn. 12191 Kirkham Rd., Poway, CA. 92064 | 800.458.5448 | apricorn.com | Patents: apricorn.com/patents
