L-Shape Pinhole Covert
Hardware Manual
Q113, Q115
2016/06 6 /1
www.acti.com
Hardware Manual
2
Table of Contents
Precautions 4
Safety Instructions ........................................................................... 6
Introduction 7
The List of Models ............................................................................ 7
Package Contents ............................................................................. 8
Physical Description ........................................................................ 9
Mounting Solutions ........................................................................ 11
Installing the Main Unit 12
Mounting on DIN Rail ..................................................................... 12
Using the Bundled Mounting Rail ................................................. 12
Installing the Camera with the Surface Mount 13
Step 1: Mount the Camera ............................................................. 13
Step 2: Route and Connect the Camera Cable ............................. 14
Step 3: Connect to the Network ..................................................... 14
Step 4: Access the Camera Live View ........................................... 15
Installing the Camera Using the Flush Mount 16
Step 1: Install the Flush Mount ...................................................... 16
Step 2: Mount the Camera ............................................................. 18
Step 3: Route and Connect the Camera Cable ............................. 19
Step 4: Connect to the Network ..................................................... 19
Step 5: Access the Camera Live View ........................................... 20
Installing the Camera Using the Tilted Mount 21
Step 1: Install the Tilted Mount ...................................................... 21
Step 2: Mount the Camera ............................................................. 22
www.acti.com
Hardware Manual
3
Step 3: Route and Connect the Camera Cable ............................. 22
Step 4: Connect to the Network ..................................................... 23
Step 5: Access the Camera Live View ........................................... 24
Cable Connections 25
Connecting a Power Adapter (Optional) ....................................... 25
Connecting DI/DO Devices (Optional) ........................................... 27
Connecting Audio In / Out Devices (Optional) ............................. 30
Connecting Serial Devices (Optional) ........................................... 31
Other Accessories 32
How to Install / Remove the Memory Card ................................... 32
How to Insert the Memory Card ................................................... 32
How to Remove the Memory Card ............................................... 33
How to Shorten the Camera Cable ................................................ 34
Accessing the Camera 37
Configure the IP Addresses ........................................................... 37
Access the Camera ......................................................................... 41
Produktspezifikationen
Marke: | ACTi |
Kategorie: | Sicherheitskamera |
Modell: | Q113 |
Schutzfunktion: | Vibrationsbeständig |
E-Mail: | Ja |
Upgradefähige Firmware: | Ja |
WLAN: | Nein |
Bluetooth: | Nein |
Breite: | 75 mm |
Tiefe: | 30 mm |
Gewicht: | 508 g |
Produktfarbe: | Black, White |
Übertragungstechnik: | Kabelgebunden |
Höhe: | 100.33 mm |
Energiequelle: | DC, PoE |
Befestigungstyp: | Tisch/Wand |
Betriebstemperatur: | -30 - 60 °C |
Relative Luftfeuchtigkeit in Betrieb: | 10 - 85 % |
Netzstandard: | IEEE 802.1x, IEEE 802.3af |
Unterstützte Sicherheitsalgorithmen: | 802.1x RADIUS |
Unterstützte Netzwerkprotokolle: | IPv4/v6, TCP, UDP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, NTP, RTP, RTSP, RTCP, SMTP, FTP, IGMP, ICMP, ARP, Bonjour, UPnP, QoS, SNMP, IEEE 802.1X |
Automatische Gewinnkontrolle: | Ja |
Sprachcodec: | G.711 |
Zertifizierung: | CE, FCC, EN50155, UL |
Anzahl Ethernet-LAN-Anschlüsse (RJ-45): | 1 |
Typ: | IP-Sicherheitskamera |
Plug & Play: | Ja |
Audio Kanäle: | 1 Kanäle |
Audio-System: | 2-Wege |
Unterstützte Grafik-Auflösungen: | 320 x 240,640 x 480 (VGA),800 x 600 (SVGA),1280 x 720 (HD 720),1920 x 1080 (HD 1080) |
Fernbedienung: | Ja |
Geräuschunterdrückung: | Ja |
Größe des Bildsensors: | 1/2.8 " |
Formfaktor: | Verdeckt |
Kompatible Speicherkarten: | MicroSDHC, MicroSDXC |
Webbrowser: | Ja |
Web-basiertes Management: | Ja |
Integrierter Kartenleser: | Ja |
Videokompressionsformate: | H.264, M-JPEG |
Maximale Auflösung: | 1920 x 1080 Pixel |
Ethernet Schnittstellen Typ: | Schnelles Ethernet |
Verkabelungstechnologie: | 10/100Base-T(X) |
IP-Adressen Filter: | Ja |
Reset-Knopf: | Ja |
DC-Ausgang Volt: | 12 |
Passwortschutz: | Ja |
Samplerate: | 8 kHz |
Bis zu 30 Frames pro Sekunde: | 30 fps |
Megapixel insgesamt: | 2 MP |
Anzahl der Kameras: | 1 |
Mindestbeleuchtung: | 0.1 Lux |
Anzahl der Linsen: | 1 |
Eingebaute HDD: | Nein |
Videostreaming: | Ja |
Sensor-Typ: | CMOS |
Bildqualitätsanpassung: | Brightness, Contrast, Sharpness |
Nachtsicht: | Nein |
Wide Dynamic Range (WDR): | Ja |
Anzahl der Sensoren: | 1 |
Vollbildverfahren: | Ja |
Anzahl der effektiven Pixel (H x V): | 1944 x 1224 Pixel |
Maximale Blendenzahl: | 2.5 |
Geräuschunterdrückungstechnologie: | Ultra 2D noise reduction, Ultra 3D noise reduction |
Flip & Spiegel: | Ja |
Datenschutz-Maskierung: | Ja |
Bitratenkontrolle: | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Übertragungsgeschwindigkeit: | 28 Kbps - 6 Mbps |
Digital Wide Dynamic Range (DWDR): | Ja |
Region of Interest-(ROI)-Kodierung: | Ja |
Video-Bewegungsmelder: | Ja |
Herzschlag: | Ja |
Spiegel: | Ja |
Digitales Wasserzeichen: | Ja |
Intelligent Video Surveillance-(IVS)-System-Eigenschaften: | Abandoned object, Crossing line, Face detection, Intrusion, Missing object, People counting, Scene change |
Verhaltensanalyse: | Intrusion detection, Line crossing detection, Object removal detection, Unattended baggage detection |
Stromverbrauch (Power over Ethernet (PoE)): | 4.32 W |
Betrachtungswinkel (horizontal): | 84.5 ° |
Betrachtungswinkel (vertikal): | 46.5 ° |
Feste Brennweite: | 3.7 mm |
Warnbenachrichtigungstyp: | E-mail, Snapshot alert message, Text alert message |
HTTPS-Verschlüsselung: | Ja |
Passwortschutz-Art: | Benutzer |
Audio input Kanäle: | 1 Kanäle |
Fester Fokus: | Ja |
Verstärkungssteuerungstyp: | Auto |
Streaming-Verfahren: | Multicasting |
Textüberlagerung: | Ja |
Zeitstempel-Überlagerung: | Ja |
Ansicht aus der Ferne: | Ja |
Aktiver Fälschungsalarm: | Ja |
Anti-Flimmern: | Ja |
3D (Geräuschunterdrückung): | Ja |
Personenzählfunktion: | Ja |
Terminalblock-Anschluss: | Ja |
Datenschutz: | Ja |
Anzahl der TV-Linien (horizontal): | 1100 |
Ethernet/LAN: | Ja |
Unterstützte Positionierung: | Drinnen |
